21 Disposal
Installation and operation manual
45
RXYQQ8~20U7Y1B
VRV IV Q+ series heat pump
4P546221-1B – 2020.10
R7T Thermistor (heat exchanger, de-icer)
R8T, R9T Thermistor (M1C, M2C body)
R21T, R22T Thermistor (M1C, M2C discharge)
S1NPH Pressure sensor (high)
S1NPL Pressure sensor (low)
S1PH,
S2PH
Pressure switch (discharge)
SEG1~SEG
3 (A1P)
7-segment display
T1A Current sensor
V1D (A3P) Diode
V1R (A3P,
A4P, A6P,
A7P)
Power module
X*A Connector
X1M (A1P) Terminal block (control)
X1M (A8P) Terminal block (power supply)(option)
Y1E Electronic expansion valve (main)
Y2E Electronic expansion valve (sub‑cool)
Y3E Electronic expansion valve (liquid cooling)
Y1S Solenoid valve (main)
Y2S Solenoid valve (accumulator oil return)
Y3S Solenoid valve (oil 1)
Y4S Solenoid valve (oil 2)
Z*C Noise filter (ferrite core)
Z*F (A2P) Noise filter (with surge absorber)
Connectors for optional accessories:
X10A Connector (drainpan heater)
X37A Connector (power adapter)
X66A Connector (remote switching COOL/HEAT selector)
21 Disposal
NOTICE
Do NOT try to dismantle the system yourself: dismantling
of the system, treatment of the refrigerant, oil and other
parts MUST comply with applicable legislation. Units
MUST be treated at a specialised treatment facility for
reuse, recycling and recovery.
