18 Hand-over to the user
Installation and operation manual
32
RXMLQ8 + RXYLQ10~14T7Y1B*
VRV IV system air conditioner
4P543426-1C – 2025.01
Installation date and field setting
Be sure to keep record of the installation date on the
sticker on the rear of the upper front panel according to
EN60335‑2‑40 and keep record of the contents of the field
setting(s).
17.3 About the system test run
NOTICE
Make sure to carry out the test run after the first
installation. Otherwise, the malfunction code will be
displayed on the user interface and normal operation or
individual indoor unit test run cannot be carried out.
The procedure below describes the test operation of the complete
system. This operation checks and judges following items:
▪ Check for incorrect wiring (communication check with indoor
unit(s)).
▪ Check of the stop valves opening.
▪ Judgement of piping length.
In case Hydrobox units or RA DX indoor units are present in the
system, the pipe length check will not be performed.
▪ Abnormalities on indoor units cannot be checked for each unit
separately. After the test operation is finished, check the indoor
units one by one by performing a normal operation using the user
interface. Refer to the indoor unit installation manual for more
details (e.g., Hydrobox) concerning the individual test run.
INFORMATION
▪ It may take 10 minutes to achieve a uniform refrigerant
state before the compressor starts.
▪ During the test operation, the refrigerant running sound
or the magnetic sound of a solenoid valve may become
loud and the display indication may change. These are
not malfunctions.
17.4 To perform a test run
1 Make sure all field settings you want are set; see "16.1Making
field settings"[428].
2 Turn ON the power to the outdoor unit and the connected
indoor unit(s).
NOTICE
Turn ON the power 6 hours before operation in order to
have power running to the crankcase heater and to protect
the compressor.
3 Make sure the default (idle) situation is existing; see "16.1.4To
access mode 1 or 2"[429]. Push BS2 for 5 seconds or more.
The unit will start test operation.
Result: The test operation is automatically carried out, the
outdoor unit display will indicate " " and the indication "Test
operation" and "Under centralised control" will display on the
user interface of the indoor unit(s).
Steps during the automatic system test run procedure:
In case:
▪ Setting [2-4]=0
▪ OR room temperature ≥25°C:
Step Description
Control before start up (pressure equalisation)
Cooling start up control
Cooling stable condition
Communication check
Stop valve check
Step Description
Pipe length check
Refrigerant amount check (NOT in case of
Hydrobox, RA or AHU connection)
Unit stop
In case:
▪ Setting [2-4]=1 or 2
▪ AND room temperature <25°C:
Step Description
Control before start up (pressure equalisation)
Heating start up control
Communication check + Stop valve check
Pre-heating operation (ONLY if setting [2-4]=2)
+ Heating pump down control
Cooling start up control
Unit stop
INFORMATION
During the test operation, it is not possible to stop the unit
operation from a user interface. To abort the operation,
press BS3. The unit will stop after ±30 seconds.
4 Check the test operation results on the outdoor unit 7‑segment
display.
Completion Description
Normal completion No indication on the 7‑segment display (idle).
Abnormal
completion
Indication of malfunction code on the
7‑segment display.
Refer to "17.5Correcting after abnormal
completion of the test run"[432] to take
actions for correcting the abnormality. When
the test operation is fully completed, normal
operation will be possible after 5 minutes.
17.5 Correcting after abnormal
completion of the test run
The test operation is only completed if there is no malfunction code
displayed on the user interface or outdoor unit 7‑segment display. In
case of a displayed malfunction code, perform correcting actions as
explained in the malfunction code table. Carry out the test operation
again and confirm that the abnormality is properly corrected.
INFORMATION
Refer to the installation manual of the indoor unit for
detailed malfunction codes related to indoor units.
18 Hand-over to the user
Once the test run is finished and the unit operates properly, make
sure the following is clear for the user:
▪ Make sure that the user has the printed documentation and ask
him/her to keep it for future reference. Inform the user that he/she
can find the complete documentation at the URL mentioned earlier
in this manual.
▪ Explain to the user how to properly operate the system and what
to do in case of problems.
▪ Show the user what to do for the maintenance of the unit.
