16 Configuration
Installation and operation manual
30
RXMLQ8 + RXYLQ10~14T7Y1B*
VRV IV system air conditioner
4P543426-1C – 2025.01
Code Shows ...
[1‑6] The current T
c
target parameter position
[1‑10]
Shows the total number of connected indoor units.
[1‑13]
Shows the total number of connected outdoor units (in case of
multiple outdoor system).
[1‑17] [1‑18] [1‑19]
Code Shows ...
[1‑17] The latest malfunction code
[1‑18] The 2nd last malfunction code
[1‑19] The 3rd last malfunction code
[1‑38] [1‑39]
Code Shows ...
[1‑38] The number of RADX indoor units connected
to the system.
[1‑39] The number of Hydrobox (HXY080/125) indoor
units connected to the system.
[1‑40] [1‑41]
Code Shows ...
[1‑40] The current cooling comfort setting
[1‑41] The current heating comfort setting
16.1.8 Mode 2: field settings
[2‑0]
Cool/Heat selection setting.
[2‑0] Description
0 (default) Each individual outdoor unit can select Cool/
Heat operation (by Cool/Heat selector if
installed), or by defining master indoor user
interface (see setting [2‑83] and the operation
manual).
1 Master unit decides Cool/Heat operation when
outdoor units are connected in multiple system
combination
(a)
.
2 Slave unit for Cool/Heat operation when
outdoor units are connected in multiple system
combination
(a)
.
(a)
It is necessary to use the optional external control adaptor for
outdoor unit (DTA104A61/62). See the instruction delivered with
the adaptor for further details.
[2‑4]
Cooling/heating test run setting.
For settings 1 and 2, in case room temperature is below 25°C and
ambient temperature is below 15°C, a part of the check operation
changes to heating operation. The difference between setting 1 and
2 is that setting 2 has additional heating operation to warm up the
room (maximum 30 minutes), before cooling check operation.
[2‑4] Description
0 (default) Cooling check operation.
1 Heating and cooling check operation.
2 Heating and cooling check operation.
[2‑8]
T
e
target temperature during cooling operation.
[2‑8] T
e
target [°C]
0 (default) Auto
[2‑8] T
e
target [°C]
2 6
3 7
4 8
5 9
6 10
7 11
[2‑9]
T
c
target temperature during heating operation.
[2‑9] T
c
target (°C)
0 (default) Auto
1 41
3 43
6 46
[2‑20]
Manual additional refrigerant charge.
[2‑20] Description
0 (default) Deactivated.
1 Activated.
To stop the manual additional refrigerant
charge operation (when the required additional
refrigerant amount is charged), push BS3. If
this function was not aborted by pushing BS3,
the unit will stop its operation after 30minutes.
If 30minutes was not sufficient to add the
needed refrigerant amount, the function can be
reactivated by changing the field setting again.
[2‑35]
Height difference setting.
[2‑35] Description
0 In case the outdoor unit is installed in the
lowest position (indoor units are installed on a
higher position than outdoor units) and the
height difference between the highest indoor
unit and the outdoor unit exceeds 40m, the
setting [2‑35] should be changed to 0.
1 (default) —
[2‑49]
Height difference setting.
[2‑49] Description
0 (default) —
1 In case the outdoor unit is installed in the
highest position (indoor units are installed on a
lower position than outdoor units) and the
height difference between the lowest indoor
unit and the outdoor unit exceeds 50m, the
setting [2‑49] has to be changed to 1.
[2‑83]
Master user interface allocation in case VRV DX indoor units and
RADX indoor units are used at the same time.
[2‑83] Description
0 VRVDX indoor unit has mode selection right.
1 (default) RADX indoor unit has mode selection right
setting.
