12 Technical data
Installation manual
15
RXF50~71D5V1B
R32 split series
3P645642-2E – 2021.10
HPS
7.0 CuT
7.0 CuT
7.0 CuT
7.0 CuT
7.0 CuT
7.0 CuT
12.7 CuT
12.7 CuT
12.7 CuT
12.7 CuT
12.7 CuT
12.7 CuT
9.5 CuT
6.4 CuT
9.5 CuT
6.4 CuT
6.4 CuT
6.4 CuT
6.4 CuT
4.0 CuT
4.0 CuT
4.0 CuT
9.5 CuT
12.7 CuT12.7 CuT
6.4 CuT
RXF60D, RXF71D
b
a
c
d
f
h
g
j1
j3
j2
k
m
m
m
m
m
n
M
o
e
l
i
i
i
a
Liquid field piping j3 Discharge pipe thermistor
b
Gas field piping k Heat exchanger
c
Liquid stop valve l 4-way valve (ON: heating)
d
Gas stop valve m Muffler
e
Liquid receiver n Compressor
f
Filter o Accumulator
g
Electronic expansion valve HPS High pressure switch (automatic reset)
h
Muffler with filter M Propeller fan
i
Capillary tube
Refrigerant flow: cooling
j1
Outdoor temperature thermistor Refrigerant flow: heating
j2
Heat exchanger thermistor
