8 | Electrical installation

Installer reference guide

RXF20~42E5V1B+ARXF20~42E5V1B

R32 split series

4P519439-21V – 2022.10

8 Electrical installation

In this chapter

8.1 Preparing electrical wiring...................................................................................................................................................... 45

8.1.1 About preparing electrical wiring .......................................................................................................................... 45

8.2 Connecting the electrical wiring............................................................................................................................................. 46

8.2.1 About connecting the electrical wiring.................................................................................................................. 46

8.2.2 Precautions when connecting the electrical wiring .............................................................................................. 46

8.2.3 Guidelines when connecting the electrical wiring ................................................................................................ 47

8.2.4 Specifications of standard wiring components ..................................................................................................... 48

8.2.5 To connect the electrical wiring to the outdoor unit ............................................................................................ 48

8.1 Preparing electrical wiring

8.1.1 About preparing electrical wiring

INFORMATION

Also read the precautions and requirements in the "2 General safety

precautions"[46].

INFORMATION

Also read "8.2.4Specifications of standard wiring components"[448].

WARNING

▪ If the power supply has a missing or wrong N-phase, equipment might break

down.

▪ Establish proper earthing. Do NOT earth the unit to a utility pipe, surge absorber,

or telephone earth. Incomplete earthing may cause electrical shock.

▪ Install the required fuses or circuit breakers.

▪ Secure the electrical wiring with cable ties so that the cables do NOT come in

contact with sharp edges or piping, particularly on the high-pressure side.

▪ Do NOT use taped wires, extension cords, or connections from a star system.

They can cause overheating, electrical shock or fire.

▪ Do NOT install a phase advancing capacitor, because this unit is equipped with an

inverter. A phase advancing capacitor will reduce performance and may cause

accidents.

WARNING

▪ All wiring MUST be performed by an authorised electrician and MUST comply

with the applicable national wiring regulation.

▪ Make electrical connections to the fixed wiring.

▪ All components procured on-site and all electrical construction MUST comply

with the applicable legislation.

WARNING

ALWAYS use multicore cable for power supply cables.
