6 | Unit installation

Installer reference guide

RXF20~42E5V1B+ARXF20~42E5V1B

R32 split series

4P519439-21V – 2022.10

6 Unit installation

In this chapter

6.1 Preparing the installation site ................................................................................................................................................ 25

6.1.1 Installation site requirements of the outdoor unit ............................................................................................... 26

6.1.2 Additional installation site requirements of the outdoor unit in cold climates ................................................... 28

6.2 Opening the units ................................................................................................................................................................... 29

6.2.1 About opening the units ........................................................................................................................................ 29

6.2.2 To open the outdoor unit ...................................................................................................................................... 29

6.3 Mounting the outdoor unit .................................................................................................................................................... 29

6.3.1 About mounting the outdoor unit ......................................................................................................................... 29

6.3.2 Precautions when mounting the outdoor unit...................................................................................................... 30

6.3.3 To provide the installation structure ..................................................................................................................... 30

6.3.4 To install the outdoor unit ..................................................................................................................................... 30

6.3.5 To provide drainage ............................................................................................................................................... 31

6.3.6 To prevent the outdoor unit from falling over ...................................................................................................... 31

6.1 Preparing the installation site

Choose an installation location with sufficient space to transport the unit in and

out of the site.

Do NOT install the unit in places often used as work place. In case of construction

works (e.g. grinding works) where a lot of dust is created, the unit MUST be

covered.

CAUTION

▪ Check if the installation location can support the unit's weight. Poor installation is

hazardous. It can also cause vibrations or unusual operating noise.

▪ Provide sufficient service space.

▪ Do NOT install the unit so that it is in contact with a ceiling or a wall, as this may

cause vibrations.

▪ Choose a location where the operation noise or the hot/cold air discharged from

the unit will not disturb anyone and the location is selected according the

applicable legislation.

▪ Provide sufficient space around the unit for servicing and air circulation.

▪ Avoid areas where flammable gas or product might leak.

▪ Install units, power cables and communication wiring at least 3 m away from

televisions or radios to prevent interference. Depending on the radio waves, a

distance of 3m may not be sufficient.

WARNING

Do NOT place objects below the indoor and/or outdoor unit that may get wet.

Otherwise condensation on the unit or refrigerant pipes, air filter dirt or drain

blockage may cause dripping, and objects under the unit may get dirty or damaged.

WARNING

The appliance shall be stored in a room without continuously operating ignition

sources (example: open flames, an operating gas appliance or an operating electric

heater).
