8 Troubleshooting
Installation and operation manual
14
REMA5+REYA8~20A7Y1B
VRV 5 heat recovery
4P684060-1C – 2024.10
Main code Contents
Discharge air thermistor malfunction (indoor)
Movement detector or floor temperature sensor
malfunction (indoor)
R32 sensor malfunction in one of the indoor units
(a)
R32 sensor end of lifetime in one of the indoor units
(a)
R32 sensor end of lifetime<6months in one of the
indoor units
(a)
Waiting for indoor unit R32 sensor replacement input
(a)
Waiting for BS unit replacement input
BS unit R32 sensor malfunction
Less than 6 months before the BS unit R32 sensor
end of lifetime
BS unit R32 sensor end of lifetime
User interface thermistor malfunction (indoor)
PCB malfunction (outdoor)
Current leakage detector was activated (outdoor)
High pressure switch was activated
Low pressure malfunction (outdoor)
Compressor lock detection (outdoor)
Fan motor malfunction (outdoor)
Electronic expansion valve malfunction (outdoor)
BS unit damper malfunction
Discharge temperature malfunction (outdoor)
Abnormal suction temperature (outdoor)
Refrigerant overcharge detection
High pressure switch malfunction
Low pressure switch malfunction
Fan motor malfunction (outdoor)
Ambient temperature sensor malfunction (outdoor)
Discharge temperature sensor malfunction (outdoor)
Suction temperature sensor malfunction (outdoor)
De-icing temperature sensor malfunction (outdoor) or
heat exchanger gas temperature sensor malfunction
(outdoor)
Liquid temperature sensor (after subcool HE)
malfunction (outdoor)
Liquid temperature sensor (coil) malfunction (outdoor)
Gas temperature sensor (after subcool HE)
malfunction (outdoor)
High pressure sensor malfunction (S1NPH)
Low pressure sensor malfunction (S1NPL)
INV PCB abnormal
Fin temperature abnormal
INV PCB abnormal
Compressor over current detected
Compressor lock (startup)
Transmission outdoor unit - inverter: INV transmission
trouble
INV unbalanced power supply voltage
Fin thermistor malfunction
Capacity setting malfunction (outdoor)
Abnormal low pressure drop, faulty expansion valve
Reversed power supply phase malfunction
INV voltage power shortage
System test run not yet executed
Faulty wiring indoor/BS unit/outdoor
Main code Contents
Abnormal user interface - indoor communication
Faulty wiring to outdoor/outdoor
Warning because there is an error on another unit
(indoor/BS unit)
Connection malfunction over indoor units or type
mismatch
System lock
External ventilation input error
Centralised address duplication
Malfunction in communication centralised control
device - indoor unit
Faulty wiring indoor/BS unit
Auto address malfunction (inconsistency)
Airflow rate below the legal limit (for EKEA/EKVDX)
(a)
The error code is only shown on the user interface of the indoor
unit where the error occurs.
8.2 Symptoms that are NOT system
malfunctions
The following symptoms are NOT system malfunctions:
8.2.1 Symptom: The system does not operate
▪ The air conditioner does not start immediately after the ON/OFF
button on the user interface is pressed. If the operation lamp
lights, the system is in normal condition. To prevent overloading of
the compressor motor, the air conditioner starts 5 minutes after it
is turned ON again in case it was turned OFF just before. The
same starting delay occurs after the operation mode selector
button was used.
▪ If "Under Centralised Control" is displayed on the user interface,
pressing the operation button causes the display to blink for a few
seconds. The blinking display indicates that the user interface
cannot be used.
▪ The system does not start immediately after the power supply is
turned on. Wait one minute until the microcomputer is prepared for
operation.
8.2.2 Symptom: Fan operation is possible, but
cooling and heating do not work
Immediately after the power is turned on. The micro computer is
getting ready to operate and is performing a communication check
with the indoor unit(s). Please wait 12 minutes maximally until this
process is finished.
8.2.3 Symptom: The fan speed does not
correspond to the setting
The fan speed does not change even if the fan speed adjustment
button is pressed. During heating operation, when the room
temperature reaches the set temperature, the outdoor unit goes off
and the indoor unit changes to whisper fan speed. This is to prevent
cold air blowing directly on occupants of the room. The fan speed
will not change even when another indoor unit is in heating
operation, if the button is pressed.
8.2.4 Symptom: The fan direction does not
correspond to the setting
The fan direction does not correspond with the user interface
display. The fan direction does not swing. This is because the unit is
being controlled by the micro computer.
