1 About the documentation
Installation and operation manual
4
LREN8~12A + LRNUN5A
CO₂ ZEAS outdoor unit and capacity up unit
4P704141-1F – 2024.12
1 About the documentation
1.1 About this document
In this documentation, the term "indoor units" is used for refrigeration
units, unless mentioned otherwise.
Target audience
Authorised installers + end users
INFORMATION
This appliance is intended to be used by expert or trained
users in shops, in light industry and on farms, or for
commercial use by lay persons.
Documentation set
This document is part of a documentation set. The complete set
consists of:
▪ General safety precautions:
▪ Safety instructions that you must read before installing
▪ Format: Paper (in the box of the outdoor unit)
▪ Installation and operation manual of the outdoor unit:
▪ Installation and operation instructions
▪ Format: Paper (in the box of the outdoor unit)
▪ Installer and user reference guide of the outdoor unit:
▪ Preparation of the installation, reference data,…
▪ Detailed step-by-step instructions and background information
for basic and advanced usage
▪ Format: Digital files on https://www.daikin.eu. Use the search
function to find your model.
▪ CO
2
ZEAS heat recovery connection instruction:
▪ Preparation of the installation, reference data,…
▪ Format: Digital files on https://www.daikin.eu. Use the search
function to find your model.
The latest revision of the supplied documentation is published on the
regional Daikin website and is available via your dealer.
The original instructions are written in English. All other languages
are translations of the original instructions.
Technical engineering data
▪ A subset of the latest technical data is available on the regional
Daikin website (publicly accessible).
▪ The full set of the latest technical data is available on the Daikin
Business Portal (authentication required).
2 Specific installer safety
instructions
Always observe the following safety instructions and regulations.
General installation requirements
WARNING
▪ Install all necessary countermeasures in case of
refrigerant leakage according to standard EN378 (see
"12.1.3Additional installation site requirements for CO₂
refrigerant"[417]).
▪ Install a CO
2
leak detector (field supply) in every room
with refrigerant piping, showcases or blower coils, and -
if present - enable the function for refrigerant leak
detection (see the installation manual of the indoor
units).
WARNING
Make sure installation, servicing, maintenance, repair and
applied materials follow the instructions from Daikin
(including all documents listed in “Documentation set”)
and, in addition, comply with applicable legislation and are
performed by qualified persons only. In Europe and areas
where IEC standards apply, EN/IEC 60335-2-40 is the
applicable standard.
CAUTION
Do NOT insert fingers, rods or other objects into the air
inlet or outlet. When the fan is rotating at high speed, it will
cause injury.
About the box (see "10About the box"[412])
WARNING
A CO
2
detector is ALWAYS recommended during storage
and transport.
WARNING
Tear apart and throw away plastic packaging bags so that
nobody, especially children, can play with them. Possible
consequence: suffocation.
CAUTION
To avoid injury, do NOT touch the air inlet or aluminium
fins of the unit.
WARNING
Do NOT use the middle opening of the outdoor unit to
attach the belts.
ALWAYS use the outer openings.
WARNING
Do NOT use the outer left opening of the outdoor unit for
lifting the unit with a forklift.
About the unit and options (see "11About the units and
options"[414])
WARNING
ONLY the refrigeration parts that are also designed to work
with R744 (CO
2
) shall be connected to the system.
Unit installation (see "12Unit installation"[417])
DANGER: RISK OF BURNING/SCALDING
DANGER: RISK OF ELECTROCUTION
WARNING
Follow the service space dimensions in this manual to
install the unit correctly. See "12.1.1 Installation site
requirements of the outdoor unit"[417].
WARNING
Fix the unit correctly. For instructions, see "12 Unit
installation"[417].
WARNING
Fixing method of the outdoor unit MUST be in accordance
with the instructions from this manual. See "12.3Mounting
the outdoor unit"[420].
