7 Maintenance and service
Installation and operation manual
11
FXZA15~50A2VEB
VRV system air conditioner
3P599603-1E – 2024.02
6.2.2 Special heating operation modes
Operation Description
Defrost To prevent a loss of heating capacity due to frost
accumulation in the outdoor unit, the system will
automatically switch to defrost operation.
During defrost operation, the indoor unit fan will stop
operation, and the following icon will appear on the
home screen:
The system will resume normal operation after
approximately 6 to 8 minutes.
Hot start During hot start, the indoor unit fan will stop
operation, and the following icon will appear on the
home screen:
6.2.3 Adjusting the airflow direction
The following airflow directions can be set:
Direction Screen
Fixed position. The indoor unit
blows air in 1 of 4 fixed positions.
Swing. The indoor unit alternates
between the 4 positions.
Auto. The indoor unit adjusts its
airflow direction according to
movement sensed by a
movement sensor.
INFORMATION
Depending on system layout and organisation, Auto airflow
direction may not be available.
INFORMATION
For setting procedure of the airflow direction, see the
reference guide or the manual of the used user interface.
Automatic airflow control
Cooling Heating
▪ When the room temperature is
lower than the controller's
setpoint for cooling operation
(including auto operation).
▪ When the indoor units run in
Continuous operation, and the
airflow direction is downward.
▪ When starting operation.
▪ When the room temperature is
higher than the controller's
setpoint for heating operation
(including auto operation).
▪ At defrost operation.
▪ When the indoor units run continuously for a long time and the
airflow direction is Horizontal.
WARNING
NEVER touch the air outlet or the horizontal blades while
the swing flap is in operation. Fingers may become caught
or the unit may break down.
NOTICE
Avoid operating in the horizontal direction. It may cause
dew or dust to settle on the ceiling or flap.
6.3 To operate the system
INFORMATION
For setting of the operation mode, airflow direction or other
settings, see the reference guide or operation manual of
the user interface.
7 Maintenance and service
7.1 Precautions for maintenance and
service
CAUTION
See "3 User safety instructions" [4 6] to acknowledge all
related safety instructions.
NOTICE
NEVER inspect or service the unit by yourself. Ask a
qualified service person to perform this work. However, as
end user, you may clean the air filter, suction grille, air
outlet and outside panels.
NOTICE
Maintenance MUST be done by an authorised installer or
service agent.
We recommend performing maintenance at least once a
year. However, applicable legislation might require shorter
maintenance intervals.
NOTICE
Do NOT wipe the controller operation panel with benzine,
thinner, chemical dust cloth, etc. The panel may get
discoloured or the coating peeled off. If it is heavily dirty,
soak a cloth in water-diluted neutral detergent, squeeze it
well and wipe the panel clean. Wipe it with another dry
cloth.
Following symbols may occur on the indoor unit:
Symbol Explanation
Measure the voltage at the terminals of main circuit
capacitors or electrical components before servicing.
DANGER: RISK OF ELECTROCUTION
Disconnect the power supply for more than 10 minutes,
and measure the voltage at the terminals of main circuit
capacitors or electrical components before servicing. The
voltage MUST be less than 50VDC before you can touch
electrical components. For the location of the terminals,
see the warning label for persons performing service and
maintenance.
