8 Troubleshooting
Installation and operation manual
14
FXZA15~50A2VEB
VRV system air conditioner
3P599603-1E – 2024.02
In case of detection when the unit is operating
1 The user interface displays error "A0-11" and emits an alarm
sound. The status indicator blinks.
2 Contact your dealer immediately. For more information, see the
installation manual of the outdoor unit.
In case of detection when the unit is in standby
When the detection occurs when the unit is in standby, the unit
performs a "false detection check".
False detection check
1 The fan starts turning on the lowest setting.
2 The user interface displays error "A0-13" and emits an alarm
sound. The status indicator blinks.
3 The sensor checks if a refrigerant leakage or misdetection
occurred.
▪ No refrigerant leakage detected. Result: The system resumes
normal operation after approximately 2minutes.
▪ Refrigerant leakage detected. Result:
1 The user interface displays error "A0-11" and emits an alarm
sound. The status indicator blinks.
2 Contact your dealer immediately. For more information, see the
installation manual of the outdoor unit.
INFORMATION
The minimum airflow during normal operation or during the
refrigerant leakage detection is always >240m
3
/h.
INFORMATION
To stop the alarm of the user interface, see the reference
guide of the user interface.
8 Troubleshooting
If one of the following malfunctions occurs, take the measures
shown below and contact your dealer.
WARNING
Stop operation and shut OFF the power if anything
unusual occurs (burning smells etc.).
Leaving the unit running under such circumstances may
cause breakage, electrical shock or fire. Contact your
dealer.
The system MUST be repaired by a qualified service person.
Malfunction Measure
If a safety device such as a fuse, a
circuit breaker or a residual current
device frequently actuates or the ON/
OFF switch does NOT function properly.
Turn OFF all main power
supply switches to the
unit.
If water leaks from the unit. Stop operation.
The operation switch does NOT function
properly.
Turn OFF the power
supply.
If the user interface displays .
Notify your installer and
report the error code. To
display an error code see
the reference guide of the
user interface.
If the system does NOT operate properly except for the above
mentioned cases and none of the above mentioned malfunctions is
evident, investigate the system in accordance with the following
procedures.
INFORMATION
Refer to the reference guide located on https://
www.daikin.eu for more troubleshooting tips. Use the
search function to find your model.
If after checking all above items, it is impossible to fix the problem
yourself, contact your installer and state the symptoms, the complete
model name of the unit (with manufacturing number if possible) and
the installation date (possibly listed on the warranty card).
After checking all the items above, if it is impossible to fix the
problem yourself, contact your installer and state the symptoms, the
complete model name of the unit (with manufacturing number if
possible) and the installation date.
9 Relocation
Contact your dealer to remove and reinstall the entire unit. Moving
units requires technical expertise.
10 Disposal
NOTICE
Do NOT try to dismantle the system yourself: dismantling
of the system, treatment of the refrigerant, oil and other
parts MUST comply with applicable legislation. Units
MUST be treated at a specialised treatment facility for
reuse, recycling and recovery.
