17 | Piping installation

Installer and user reference guide

FXNA-A

VRV system air conditioner

4P785124-1 – 2024.09

17 Piping installation

In this chapter

17.1 Preparing refrigerant piping................................................................................................................................................... 59

17.1.1 Refrigerant piping requirements ........................................................................................................................... 59

17.1.2 Refrigerant piping insulation ................................................................................................................................. 60

17.2 Connecting the refrigerant piping.......................................................................................................................................... 60

17.2.1 About connecting the refrigerant piping............................................................................................................... 60

17.2.2 Precautions when connecting the refrigerant piping ........................................................................................... 61

17.2.3 Guidelines when connecting the refrigerant piping ............................................................................................. 62

17.2.4 Pipe bending guidelines ......................................................................................................................................... 62

17.2.5 To flare the pipe end.............................................................................................................................................. 62

17.2.6 To connect the refrigerant piping to the indoor unit............................................................................................ 63

17.1 Preparing refrigerant piping

17.1.1 Refrigerant piping requirements

CAUTION

Piping MUST be installed according to instructions given in "17 Piping

installation" [4 59]. Only mechanical joints (e.g. braze+flare connections) that are

compliant with the latest version of ISO14903 can be used.

CAUTION

▪ When mechanical connectors are re-used indoors, renew the sealing parts.

▪ When flared joints are re-used indoors, re-make the flared part.

NOTICE

The piping and other pressure-containing parts shall be suitable for refrigerant. Use

phosphoric acid deoxidised seamless copper for refrigerant piping.

INFORMATION

Also read the precautions and requirements in the "2 General safety

precautions"[46].

▪ Foreign materials inside pipes (including oils for fabrication) must be ≤30 mg/

10m.

Refrigerant piping diameter

For piping connections of the indoor unit use the following piping diameters:

Class Pipe outer diameter (mm)

Liquid piping Gas piping

20~32 Ø6.4mm Ø9.5mm

40~63 Ø6.4mm Ø12.7mm

Refrigerant piping material

Piping material

Phosphoric acid deoxidised seamless copper
