Installation and operation manual

FXFA20~125A2VEB

VRV system air conditioner

3P599604-1E – 2022.02

Table of contents

1 About the documentation 4

1.1 About this document.................................................................. 4

2 Specific installer safety instructions 4

2.1 Instructions for equipment using R32 refrigerant ...................... 5

2.1.1 Installation space requirements .................................. 6

For the user 6

3 User safety instructions 6

3.1 General...................................................................................... 6

3.2 Instructions for safe operation ................................................... 7

4 About the system 9

4.1 System layout............................................................................ 10

5 User interface 10

6 Operation 10

6.1 Operation range ........................................................................ 10

6.2 About operation modes ............................................................. 10

6.2.1 Basic operation modes ............................................... 10

6.2.2 Special heating operation modes................................ 10

6.2.3 Adjusting the airflow direction ..................................... 11

6.2.4 Active circulation airflow.............................................. 11

6.3 To operate the system............................................................... 11

7 Maintenance and service 11

7.1 Precautions for maintenance and service ................................. 11

7.2 Cleaning the air filter, suction grille, air outlet and outside

panels........................................................................................ 12

7.2.1 To clean the air filter ................................................... 12

7.2.2 To clean the suction grille ........................................... 12

7.2.3 To clean the air outlet and outside panels .................. 13

7.3 About the refrigerant.................................................................. 13

7.3.1 About the refrigerant leakage sensor.......................... 13

8 Troubleshooting 14

9 Relocation 14

10 Disposal 14

For the installer 15

11 About the box 15

11.1 Indoor unit ................................................................................. 15

11.1.1 To remove the accessories from the indoor unit......... 15

12 Unit installation 15

12.1 Preparing the installation site .................................................... 15

12.1.1 Installation site requirements of the indoor unit .......... 15

12.2 Mounting the indoor unit............................................................ 16

12.2.1 Guidelines when installing the indoor unit................... 16

12.2.2 Guidelines when installing the drain piping................. 17

13 Piping installation 18

13.1 Preparing refrigerant piping....................................................... 18

13.1.1 Refrigerant piping requirements.................................. 18

13.1.2 Refrigerant piping insulation ....................................... 19

13.2 Connecting the refrigerant piping .............................................. 19

13.2.1 To connect the refrigerant piping to the indoor unit .... 19

14 Electrical installation 19

14.1 Specifications of standard wiring components .......................... 19

14.2 To connect the electrical wiring to the indoor unit ..................... 20

15 Commissioning 21

15.1 Checklist before commissioning................................................. 21

15.2 To perform a test run.................................................................. 21

16 Configuration 21

16.1 Field setting ................................................................................ 21

17 Technical data 23

17.1 Wiring diagram ........................................................................... 23

17.1.1 Unified wiring diagram legend...................................... 23

1 About the documentation

1.1 About this document

Target audience

Authorised installers + end users

INFORMATION

This appliance is intended to be used by expert or trained

users in shops, in light industry and on farms, or for

commercial use by lay persons.

WARNING

Make sure installation, servicing, maintenance, repair and

applied materials follow the instructions from Daikin and, in

addition, comply with applicable legislation and are

performed by qualified persons only. In Europe and areas

where IEC standards apply, EN/IEC 60335-2-40 is the

applicable standard.

Documentation set

This document is part of a documentation set. The complete set

consists of:

▪ General safety precautions:

▪ Safety instructions that you must read before installing

▪ Format: Paper (in the box of the indoor unit)

▪ Indoor unit installation and operation manual:

▪ Installation and operation instructions

▪ Format: Paper (in the box of the indoor unit)

▪ Installer and user reference guide:

▪ Preparation of the installation, good practices, reference data,…

▪ Detailed step-by-step instructions and background information

for basic and advanced usage

▪ Format: Digital files on https://www.daikin.eu. Use the search

function to find your model.

Latest revisions of the supplied documentation may be available on

the regional Daikin website or via your dealer.

The original documentation is written in English. All other languages

are translations.

Technical engineering data

▪ A subset of the latest technical data is available on the regional

Daikin website (publicly accessible).

▪ The full set of latest technical data is available on the Daikin

Business Portal (authentication required).

2 Specific installer safety

instructions

Always observe the following safety instructions and regulations.
