D-EOMZC00204-18_04EN 10/54
3.7 Optional Remote User Interface
As an option an external Remote HMI can be connected on the UC. The Remote HMI offers the same features as the
inbuilt display plus the alarm indication done with a light emitting diode located below the bell button.
The Remote can be ordered with the unit and shipped loose as a field installed option. It can also be ordered any time after
chiller shipment and mounted and wired on the job as explained on the following page. The remote panel is powered from
the unit and no additional power supply is required.
All viewing and setpoint adjustments available on the unit controller are available on the remote panel. Navigation is
identical to the unit controller as described in this manual.
The initial screen when the remote is turned on shows the units connected to it. Highlight the desired unit and press the
wheel to access it. The remote will automatically show the units attached to it, no initial entry is required.
The Remote HMI can be extended up to 700 m using the process bus connection available on the UC. With a daisy-chain
connection as below, a single HMI can be connected to up to 8 units. Refer to the specific HMI manual for details.
3.8 Embedded Web Interface
The MicroTech III-IV controller has an embedded web interface that can be used to monitor the unit when connected to a
local network. It is possible to configure the IP addressing of the MicroTech III-IV as a fixed IP of DHCP depending on the
network configuration.
With a common web browser a PC can connect with the unit controller entering the IP address of the controller or the host
name, both visible in the “About Chiller” page accessible without entering a password.
When connected, it will be required to enter a user name and a password. Enter the following credential to get access to
the web interface:
User Name: Daikin
Password: Daikin@Web
The Main Menu page will be displayed. The page is a copy of the onboard HMI and follows the same rules in terms of
access levels and structure.
MicroTech® III
