5.5 Circuit Pumpdown Stop Alarms
5.5.1 Discharge Temperature Sensor fault
This alarm is generated to indicate that the sensor is not reading properly.
Symptom
Cause
Solution
Circuit status is Off.
The circuit is switched off with the
normal shutdown procedure.
Bell icon is moving on controller’s
display.
String in the alarm list:
CxCmp1 OffDischTmpSen
String in the alarm log:
CxCmp1 OffDischTmpSen
String in the alarm snapshot
CxCmp1 OffDischTmpSen
Sensor is shorted.
Check for sensor integrity.
Check correct sensors operation
according information about kOhm
(k) range related to temperature
values.
Sensor is broken.
Check if sensor is shorted with a
resistance measurement.
Sensor is not properly connected
(open).
Check for correct installation of the
sensor on refrigerant circuit pipe.
Check for absence of water or
humidity on sensor electrical contacts.
Check for correct plug-in of the
electrical connectors.
Check for correct sensors wiring also
according with electrical scheme.
Reset
Notes
Local HMI
Network
Auto
5.5.2 Gas Leakage fault
This alarm indicates a gas leakage in the compressor box.
Symptom
Cause
Solution
Circuit status is Off.
The circuit is switched off with the
shutdown procedure performing a
deep pumpdown of the circuit.
Bell icon is moving on controller’s
display.
String in the alarm list:
Cx OffGasLeakage
String in the alarm log:
Cx OffGasLeakage
String in the alarm snapshot
Cx OffGasLeakage
Gas leakage in the compressors box.
Switch off the unit and perform a gas
leakage test.
Gas Leakage in the plant room.
Check if there are leakage on the unit
with a detector eventually starting
suction fans to change the air in the
room.
Gas leakage sensor fault.
Put the sensor in open air and check
that the alarm can be cleared. In case
replace the sensor or disable the
option before getting a new part.
Reset
Notes
Local HMI
Network
Auto
5.5.3 High Compressor Vfd Temperature fault
This alarm is generated to indicate that the Vfd temperature is too high to allow the compressor to run.
Symptom
Cause
Solution
Circuit status is Off.
The circuit is switched off with the
normal shutdown procedure.
Bell icon is moving on controller’s
display.
String in the alarm list:
CxCmp1 VfdOverTemp
String in the alarm log:
CxCmp1 VfdOverTemp
String in the alarm snapshot
CxCmp1 VfdOverTemp
Cooling solenoid valve is not
operating properly.
Check electrical connection of the
solenoid valve.
Check refrigerant charge. Low
refrigerant charge can cause
overheating of the Vfd electronic.
Check for obstructions in the pipe.
Vfd Heater not properly connected.
Check if Vfd heater is switched off
when the Vfd temperature increases.
Check if the contactor that commands
the Vfd heater can switch propertly.
Reset
Notes
Local HMI
Network
Auto
