EWAQ016~064BAW + EWYQ016~064BAW
Packaged air-cooled water chiller
4PW70082-1E – 2016.12
Installation and operation manual
18
LED state
Throughout the manual the state of the LEDs is indicated as follows:
Function of the push button switch which is located on the outdoor
unit PCB (A1P):
Setting the mode
The set mode can be changed with the BS1 MODE button according
to the following procedure:
Setting procedure
1 Press the BS1 MODE button for 5 seconds, until the H1P LED is
on
w.
2 Push the BS2 SET button according to the required function
(A~E). The LED indication that matches the required function is
shown below in the field marked :
3 When the BS3 RETURN button is pushed, the current setting is
defined.
4 Push the BS2 SET button according to the required setting
possibility as shown below in the field marked .
4.1 Possible settings for function A and E are ON (ON) or OFF
(OFF).
4.2 Possible settings for function B
The noise of level 3 < level 2 < level 1 ( ).
4.3 Possible settings for function C and D
For function C
(L.N.O.P.) only: the noise of level 3 < level 2
< level 1 ( ).
For function D
(DEMAND) only: the power consumption of
level 1< level 2 < level 3 ( ).
5 Push the BS3 RETURN button and the setting is defined.
6 When the BS3 RETURN button is pushed again, the operation
starts according to the setting.
Refer to the service manual for more details and for other settings.
Confirmation of the set mode
The following items can be confirmed by setting mode 1 (H1P
LED is off)
Check the LED indication in the field marked .
1 Indication of the present operation state
-
x, normal
-
w, abnormal
-
c, under preparation or under test operation
2 Indication of low noise operation state L.N.O.P.
-
x standard operation (= factory setting)
-
w L.N.O.P. operation
3 Indication of power consumption limitation setting DEMAND
-
x standard operation (= factory setting)
-
w DEMAND operation
x
OFF
w
ON
c
Blinking
BS1 MODE For changing the set mode
BS2 SET For field setting
BS3 RETURN For field setting
BS4 TEST This push button has no function
BS5 RESET This push button has no function
LED display
(Default status
before delivery)
Micro-
computer
operation
monitor
Mode
Ready/
Error
Cooling/Heating
changeover
Low
noise
Demand Multi
Indivi-
dual
Bulk
(master)
Bulk
(slave)
HAP H1P H2P H3P H4P H5P H6P H7P H8P
Single system
(a)
(a) EWA/YQ016~032 units are single system units,
EWA/YQ040~064 units are multiple system units
cxxwxxxxx
Multiple
system
(a)
Left unit
(master)
cxxwxxxxw
Right
unit
(slave)
cxxxxxxxc
INFORMATION
If you get confused in the middle of the setting process,
push the BS1 MODE button. Then it returns to setting
mode 1 (H1P LED is off).
INFORMATION
The LEDs and buttons are located in the refrigerant
module (not in the water module).
The mode can only be set on the master unit.
Possible functions
A setting of high static pressure.
B automatic low noise operation setting at nighttime.
C low noise operation level setting (L.N.O.P.) via the external control
adapter.
D power consumption limitation setting (DEMAND) via the external
control adapter.
E enabling function of the low noise operation level setting
(L.N.O.P.) and/or power consumption limitation setting
(DEMAND) via the external control adapter (DTA104A62).
H1P H2P H3P H4P H5P H6P H7P
A
w x w x x w x
B
w x w x w w x
C
w x w w x x w
D
w x w w w w x
E
w x x w w x x
H1P H2P H3P H4P H5P H6P H7P
ON
wxxxxc x
OFF
(a)
(a) This setting = factory setting
wxxxxx c
H1P H2P H3P H4P H5P H6P H7P
OFF
(a)
(a) This setting = factory setting
wxxxxx x
wxxxxx c
wxxxxc x
wxxxxc c
H1P H2P H3P H4P H5P H6P H7P
wx x x x x c
(a)
(a) This setting = factory setting
wx x x x c x
wx x xc x x
H1P H2P H3P H4P H5P H6P H7P
x xwxxxx
H1P H2P H3P H4P H5P H6P H7P
xxwxxxx
H1P H2P H3P H4P H5P H6P H7P
xxwxxxx
1
1
2
3
1
3
1
2
3
4PWEN70082-1E_2016_12.book Page 18 Wednesday, December 7, 2016 2:18 PM
