D–EOMCP00104-14EN - 39/82
6.11.3.
Other trips
Other trips may disable particular functions described in the following (e.g. heat recovery
trips).
The addition of optional expansion boards will also activate the alarms related to
communication with expansion boards and to probes connected to expansion boards.
For units with electronic expansion valve, all the drivers critical alarms will trip the
compressors
6.11.4.
Unit and compressors alarms and corresponding codes
In the following table the list of the managed alarms for both unit and compressors is shown.
Alarm code Interface alarm label Details
0 -
1 Phase Alarm Phase alarm (Unit or Circuit)
2 Freeze Alarm Freeze alarm
3 Freeze Alarm EV1 Freeze alarm on Evaporator 1
4 Freeze Alarm EV2 Freeze alarm on Evaporator 2
5 Pump Alarm Pump overload
6 Fan Overload Fan overload
7 OAT Low Pressure Low press alarm during low OAT start.
8 Low Amb Start Fail Low OAT start-up failed
9 Unit 1 Offline Board #1 offline (Master)
10 Unit 2 Offline Board #2 offline (Slave)
11 Evap. Flow Alarm Evaporator flow switch alarm
12 Probe 9 Error Inlet temperature probe fault
13 Probe 10 Error Outlet temperature probe fault
14 - -
15 Prepurge #1 Timeout Prepurge failed on circuit #1
16 Comp Overload #1 Compressor #1 overload
17 Low Press. Ratio #1 Low Pressure Ratio on circuit #1
18 High Press. Switch #1 High pressure switch alarm on circuit #1
19 High Press. Trans #1 High pressure transducer alarm on circuit #1
20 Low Press. Switch #1 Low pressure switch alarm on circuit #1
21 Low Press. Trans #1 Low pressure transducer alarm on circuit #1
22 High Disch Temp #1 High discharge temperature circuit #1
23 Probe Fault #1 Probes on circuit #1 failure
24 Transition Alarm #1 Transition alarm compressor #1
25 Low Oil Press #1 Low oil pressure on circuit #1
26 High Oil DP Alarm #1 High oil delta pressure alarm on circuit #1
27 Expansion Error Expansion boards error
28 - -
29 EXV Driver Alarm #1 EXV Driver #1 Alarm
30 EXV Driver Alarm #2 EXV Driver #2 Alarm
31 Restart after PW Loss Restart after power loss
32 - -
33 - -
