D–EOMCP00104-14EN - 36/82
single evaporator units or manifold temperature in the case of a double evaporator unit) goes out
of probe allowable range for a time longer than ten seconds.
A manual reset of the alarm will required to restart the unit
•
External alarm (only if enabled)
A “External alarm” will trip the whole unit as soon as the external alarm switch closes
after the unit start request, if the unit trip on external alarm has been set.
A manual reset of the alarm will required to restart the unit
•
Probe failure
A “Probe failure” will trip the unit if the reading of one among the following probes
goes out of probe allowable range for a time longer than ten seconds.
-
Evaporator #1 leaving temperature probe (on 2 evaporators units)
-
Evaporator #2 leaving temperature probe (on 2 evaporators units)
The controller display will show the faulted probe identification
6.11.2.
Compressors trip
Compressor trips are caused by:
•
Mechanical High pressure
A “High pressure switch alarm” will trip the compressor as soon as the high pressure
switch opens.
A manual reset of the alarm is required to restart the unit (after the manual reset of the
pressure switch).
•
High discharge pressure
A “High discharge pressure alarm” will trip the compressor as soon as the compressor
discharge pressure exceeds the adjustable high pressure setpoint.
A manual reset of the alarm are required to restart the unit
•
High discharge temperature
A “High discharge temperature alarm” will trip the compressor as soon as the
compressor discharge temperature exceeds the adjustable high temperature setpoint.
A manual reset of the alarm are required to restart the unit
•
Low evaporator outlet temperature
A “Low evaporator outlet temperature alarm” will trip the two compressors connected to
the same evaporator in the case of a double evaporator unit as soon as the evaporator leaving
water temperature falls below the adjustable freeze threshold.
A manual reset of the alarm are required to restart the unit
•
Mechanical Low pressure
A “Low pressure switch alarm” will trip the compressor if the low pressure switch opens
for more than 40 seconds during compressor running. Five automatic reset alarms (both from
transducers and switches) are managed in all modes (cooling, cooling glycol, ice, heat pump).
These alarms switch off the compressor without signalling (alarm relay is not activated). Only
the sixth will be a manual reset alarm.
