D–EOMCP00104-14EN - 15/82
4.5. Addressing of pLan/RS485
To get the correct functionality of the pLAN net system, is necessary to address correctly all
the installed components. Each component, as previously described, has a series of microswitch that
must be settled as specified in the following table.
pLAN component Microswitches
1 2 3 4 5 6
COMP. BOARD #1 ON
OFF OFF OFF OFF OFF
COMP. BOARD #2
OFF
ON
OFF OFF OFF OFF
DRIVER EXV #1 ON ON
OFF OFF OFF OFF
DRIVER EXV #2
OFF OFF
ON
OFF OFF OFF
DRIVER EXV #3 ON
OFF
ON
OFF OFF OFF
DRIVER EXV #4
OFF
ON ON
OFF OFF OFF
Additional DISPLAY ON ON ON
OFF OFF OFF
RS485 component Microswitch
1 2 3 4
EXP. BOARD #1 ON
OFF OFF OFF
EXP. BOARD #2
OFF
ON
OFF OFF
EXP. BOARD #3 ON
ON
OFF OFF
EXP. BOARD #4
OFF OFF
ON
OFF
4.6. Software
A unique control software is installed on both ASDU01C controllers (if two are present), the
unit controller is directly recognized on the basis of the pLAN address.
No software is installed on pCO
e
boards and on EEXV drivers (a factory-installed software
is used).
A pre-configuration procedure is available in each ASDU01C controller to recognize the
whole network hardware configuration; the configuration is stored in the controller in a permanent
memory and an alarm is generated if the hardware configuration would change during the operation
(network or boards faults or added boards).
The pre-configuration procedure will automatically start at the first bootstrap of the unit
(after the software is installed); it is possible to activate it manually (network refresh) if network
configuration changes, either if an expansion is permanently removed or if a new expansion is
linked after the first software bootstrap.
Changes in the network configuration without network refresh will generate alarms, either if
an expansion is removed (or faulted) or if a new expansion is added.
The configuration of functions requiring expansion boards are allowed only if expansion
boards have been recognized in the network configuration.
Network refresh is required in case of a substitution of a ASDU01C controller.
Network refresh is not required in case of a substitution of a fault expansion board already
used in the system.
