Je bekijkt pagina 22 van 82
D–EOMCP00104-14EN - 22/82
B4 SPARE DI4 Second HR pump Alarm (*)
Analog Output
Digital Output
Ch. Description Type
Ch. Description
AO1 SPARE DO1 Second water pump
DO2 SPARE
DO3 First HR pump (*)
DO4 Second HR pump (*)
(*) Optional
5.6. pCO
e
expansion #4 – Fan step control
5.6.1. Expansion connected to ASDU01C #1
Analog Input
Digital Input
Ch.
Description Type
Ch. Description
B1 Setpoint Override 4-20mA DI1 Current Limit Enable
B2 Demand Limit 4-20mA DI2 External Alarm
B3 SPARE DI3 SPARE
B4 Unit Amps. 4-20mA DI4 SPARE
Analog Output
Digital Output
Ch.
Description Type
Ch. Description
AO1
SPARE DO1 4° Fan Step comp. #1
DO2 5° Fan Step comp. #1
DO3 4° Fan Step comp. #2
DO4 5° Fan Step comp. #2
(*) Only if heat pump board is not present
5.6.2. Expansion connected to ASDU01C #2
Analog Input
Digital Input
Ch.
Description Type
Ch. Description
B1 SPARE DI1 SPARE
B2 SPARE DI2 SPARE
B3 SPARE 4-20mA DI3 SPARE
B4 SPARE 4-20mA DI4 SPARE
Analog Output
Digital Output
Ch.
Description Type
Ch. Description
AO1
SPARE DO1 4° Fan Step comp. #3
DO2 5° Fan Step comp. #3
DO3 4° Fan Step comp. #4
DO4 5° Fan Step comp. #5
(*) Only if heat pump board is not present
5.6.3. EXV Driver
Analog Input
Ch.
Description Type
B1 Suction temperature #1, #2, #3, #4 (*) NTC
B2 Suction pressure #1, #2, #3, #4 (*) 4-20mA
(*) Depending on pLan address of Driver
