D–EOMCP00104-14EN - 20/82
5.3. pCO
e
expansion #1 – Additional hardware
5.3.1. Expansion connected to ASDU01C #1
Analog Input
Digital Input
Ch. Description Type
Ch. Description
B1 Comp. Capacity Sensor #1 (*) 4-20mA DI1 SPARE
B2 Comp. Capacity Sensor #2 (*) 4-20mA DI2 SPARE
B3 Suction Temp #1 (**)
NTC
DI3 Low Pressure Switch #1 (*)
B4 Suction Temp #2 (**)
N
TC DI4 Low Pressure Switch #2 (*)
Analog Output
Digital Output
Ch. Description Type
Ch. Description
AO1 SPARE DO1 Compressor #1 alarm (*)
DO2 Compressor #2 alarm (*)
DO3 Economizer #1 (*)
DO4 Economizer #2 (*)
(*) Optional
(**) In case EEXV driver is not installed. If EEXV driver is installed, suction temperature is detected through EEXV
driver.
5.3.2. Expansion connected to ASDU01C #2
Analog Input
Digital Input
Ch. Description Type
Ch. Description
B1 Comp. Capacity Sensor #3 (*) 4-20mA DI1 SPARE
B2 Comp. Capacity Sensor #4 (*) 4-20mA DI2 SPARE
B3 Suction Temp #3 (**)
NTC
DI3 Low Pressure Switch #3 (*)
B4 Suction Temp #4 (**)
NTC
DI4 Low Pressure Switch #4 (*)
Analog Output
Digital Output
Ch. Description Type
Ch. Description
AO1 SPARE DO1 Compressor #3 alarm (*)
DO2 Compressor #4 alarm (*)
DO3 Economizer #3 (*)
DO4 Economizer #4 (*)
(*) Optional
(**) In case EEXV driver is not installed. If EEXV driver is installed, suction temperature is detected through EEXV
driver.
5.4. pCO
e
expansion #2 – Heat recovery or heat pump control
The heat recovery and heat pump options will alternative; just one of them may be used and
are specified in the manufacturer setup
5.4.1. Heat recovery option
Analog Input
Digital Input
Ch.
Description Type
Ch. Description
B1 Ambient temperature sensor DI1 Heat Recovery switch
B2 SPARE DI2 Heat Recovery Flow switch
B3 Entering HR water sensor
NTC
DI3 SPARE
B4 Leaving HR water sensor
NTC
DI4 SPARE
