D-EOMZC00106-17_07EN - 28/67
4.12.3.2 Circuit #1 (Circuit #2 if present)
This page contains all the test point, status of the digital inputs, status of the digital output and raw value of the analog
inputs associated to the Circuit #1 (or Circuit #2 if present and depending on the link followed). To activate the test point
it’s required to set the Available Modes to Test (see section 4.8) and this requires the Unit to be disabled.
Setpoint/Sub-
Menu
Default
Range
Description
Test Liq
Inj=
Off
Off/On
Test of the Liquid Injection SV
Test Var
VR=
Off
Off/On
Test of VR3 slide position
Test EXV
Pos=
0%
0-100%
Test of the Expansion Valve movements
Input/Output Values
Cir Sw
Inpt=
Off
Off/On
Status of the Circuit Enable switch
Mhp Sw
Inpt=
Off
Off/On
Status of the Mechanical High Pressure switch
Gas Leak
Inpt=
Off
Off/On
Status of the Gas Leak switch
Evap Pr
Inpt=
0.0V
0.4-4.6V
Input voltage for the Evaporator Pressure
Cond Pr
Inpt=
0.0V
0.4-4.6V
Input voltage for the Condenser Pressure
Oil Pr
Inpt=
0.0V
0.4-4.6V
Input voltage for the Oil Pressure
Gas Leak
Inpt=
0.0V
0.0-10.0V
Input voltage for the Gas Leak sensor
Suct Temp
Res=
0.0Ohm
340-300kOhm
Resistance of the Suction Temp sensor
Disc Temp
Res=
0.0Ohm
340-300kOhm
Resistance of the Discharge Temp sensor
Strtr
Outpt=
Off
Off/On
Status of the Inverter start command
Liq Inj
Outpt=
Off
Off/On
Status of the Liquid Line SV relay
Fan 1
Outpt=
Off
Off/On
Status of the Fan Output #1
Fan 2
Outpt=
Off
Off/On
Status of the Fan Output #2
Fan 3
Outpt=
Off
Off/On
Status of the Fan Output #3
Fan 4
Outpt=
Off
Off/On
Status of the Fan Output #4
Fan Vfd
Outpt=
0.0V
0-10.0V
Output voltage to the fan VFD
Variable VR
St
Off(VR2)
Off(VR2)/On(VR3)
Variable VR slide position (VR2, VR3)
4.12.4 Scheduled Maintenance
This page may contains the contact number of the Service organization taking care of this unit and the next maintenance
visit schedule.
Setpoint/Sub-Menu
Default
Range
Description
Next Maint=
Jan 2018
Schedule date for next maintenance
Support Reference=
999-999-999
Reference number or email of Service Org
