D–EIMAC01905-23_06EN - 55/65
Table 22– Standard Routine Maintenance Plan
List of activities
Weekly
Monthly
(Note 1)
Half Yearly
Yearly/Season
al (Note 2)
General:
Reading operating data (Note 3)
X
Visual inspection of unit for any damage and/or loosening
X
Verification of thermal insulation integrity
X
Clean and paint where necessary
X
Water analysis (Note 4)
X
Check of flow switch operation
X
Electrical:
Verification of control sequence
X
Verify contactor wear – Replace if necessary
X
Verify that all electrical terminals are tight – Tighten if necessary
X
Clean inside the electrical control board
X
Visual inspection of components for any signs of overheating
X
Verify operation of compressor and oil heater
X
Measure compressor motor insulation using the Megger
X
Clean air intake filters of the electrical panel
X
Verify operation of all ventilation fans in the electrical panel
X
Verify operation of inverter cooling valve and heater
X
Verify status of capacitors in the inverter (signs of damage, leaks,
etc)
X
Refrigeration circuit:
Check for any refrigerant leakage
X
Verify refrigerant flow using the liquid sight glass – Sight glass
full
X
Verify filter dryer pressure drop
X
Verify oil filter pressure drop (Note 5)
X
Analyse compressor vibrations
X
Analyse compressor oil acidity (7)
X
Check security valves (Note 5)
X
Condenser section/ Hydronic Freecooling section:
Clean water rinse condenser coils / hydronic freecooling coils
(Note 4 and 9)
X
Verify that fans are well tightened
X
Verify condenser coil fins condenser coil fins / hydronic
freecooling coils fins - Remove / Comb if necessary
X
Flexible hoses free cooling units check
X
Flexible hoses clamps tightening. Tightening torque is 10 Nm.
X
Check expansion tank pre-charge (glycol free units) (10)
X
Check expansion tank membrane conditions (glycol free units)
X
Evaporator/Heat Recovey:
Check the cleaning of the Evaporator/BPHE (Note 9)
X
Notes:
1. Monthly activities include all the weekly ones.
2. The annual (or early season) activities include all weekly and monthly activities.
3. Unit operating values should be read on a daily basis thus keeping high observation standards.
4. In environments with a high concentration of air-borne particles, it might be necessary to clean the condenser coils more often.
5. Replace the oil filter when the pressure drop across it reaches 2.0 bar.
6. Check for any dissolved metals.
7. TAN (Total Acid Number) : 0,10 : No action
Between 0.10 and 0.19 : Replace anti-acid filters and re-check after 1000 running hours. Continue to
replace filters until the TAN is lower than 0.10.
>0,19 : Replace oil, oil filter and filter dryer. Verify at regular intervals
8. Check that the cap and the seal have not been tampered with. Check that the drainage connection of the safety valves is not
accidentally occluded by foreign objects, rust or ice. Check the manufacturing date on the safety valve and replace it, if necessary,
in compliance with the national laws in force.
9. Clean condenser banks with clean water and water heat exchangers with appropriate chemicals. Particles and fibers could clog up
the exchangers, especially for water exchangers pay attention if water rich in calcium carbonate is used. An increase in pressure
drops or a decrease in thermal efficiency means that the heat exchangers are clogged. In environments with a high concentration
of air-borne particles, it might be necessary to clean the condenser bank more often.
10. Expansion vessel pre-charge is around 1.5 barg (± 20% tolerance is acceptable). It is necessary to check this value every 6 months.
To do so, use a manometer, connecting it at the valve on the vessel itself. It is necessary to check the pressure pre-charge also
every time the unit is off for more than a month.
