D–EIMAC01905-23_06EN - 30/65
Fig. 23– Mounting anti-vibration elements (supplied as optional)
4.3.2 Spring vibration dampers
Mount the vibration damper as shown in the following pictures.
1. Insert M16 screw and nut in the central hole
4.3.3 Fix the damper with the screw
Hold the screw and rotate (anticlockwise) the damper
In case of anti-vibration elements provided by a different supplier,
the load of the chiller on the anti-vibration element must be discharged on the external part of the
frame and not on the internal plate (see picture above).
