D-EIMHP01405-21_11EN 21/52
This is a palette flow switch appropriate for uninterrupted use outdoors (IP65).
The flow switch is set up to intervene when the water flow of the BPHE reaches the minimum value of the flow acceptable
(see the table below).
Modell
Flow switch Setpoint
[l/min]
EWAT/EWYT016CZ(N/P/H)-A1
22
22
EWAT/EWYT021CZ(N/P/H)-A1
22
EWAT/EWYT025CZ(N/P/H)-A1
22
EWAT/EWYT032CZ(N/P/H)-A1
31
EWAT/EWYT040CZ(N/P/H)-A1
31
EWAT/EWYT040CZ(N/P/H)-A2
57
EWAT/EWYT050CZ(N/P/H)-A2
57
EWAT/EWYT064CZ(N/P/H)-A2
57
EWAT/EWYT090CZ(N/P/H)-A2
57
Table 3 - Flow Switch Setpoint
To ensure correct operation of the unit, the value of the water flow in the evaporator must be within the declared range
for that unit. A water flow lower than the minimum value shown in the following table (table 4) could cause problems with
freezing, fouling and poor control. A water flow rate higher than the maximum value shown in table 4 will result in an
unacceptable load loss and excessive erosion of the pipes, with vibrations that can cause breakage
N – Naked Version
MODEL
Min.Flow [l/s]
Max. Flow [l/s]
EWAT/EWYT016CZN-A1
0.44
2.34
EWAT/EWYT021CZN-A1
0,84
2,66
EWAT/EWYT025CZN-A1
0,84
2,66
EWAT/EWYT032CZN-A1
1,01
2,66
EWAT/EWYT040CZN-A1
1,01
2,66
EWAT/EWYT040CZN-A2
1,41
6,00
EWAT/EWYT050CZN-A2
1,41
6,00
EWAT/EWYT064CZN-A2
1,41
6,00
EWAT/EWYT090CZN-A2
2,43
6,66
P – H.Pump-Version
MODEL
Min. Flow [l/s]
Max. Flow [l/s]
EWAT/EWYT016CZ(P/H)-A1
0,44
1,7
EWAT/EWYT021CZ(P/H)-A1
0,84
1,90
EWAT/EWYT025CZ(P/H)-A1
0,84
1,90
EWAT/EWYT032CZ(P/H)-A1
1,01
2,66
EWAT/EWYT040CZ(P/H)-A1
1,01
2,66
EWAT/EWYT040CZ(P/H)-A2
1,41
3,89
EWAT/EWYT050CZ(P/H)-A2
1,41
3,89
EWAT/EWYT064CZ(P/H)-A2
1,41
5,50
EWAT/EWYT090CZ(P/H)-A2
2,43
6,00
Table 4 –Operating limits
4.7.3 Heat recovery (optional)
Units may be optionally equipped with heat recovery system.
This system is made by a water cooled heat exchanger located on the compressors discharge pipe.
To guarantee compressor operation within its envelope, units with heat recovery cannot operate with water temperature
of the heat recovery water lower than 20°C.
It is a responsibility of plant designer and chiller installer to guarantee the respect of this value (e.g. using recirculating
bypass valve).
