EWWQ090G ÷ EWWQ720L - R410a - Water-cooled scroll chillers
EWLQ090G ÷ EWLQ720L - R410a - Condenser less
EWHQ100G ÷ EWHQ400G - R410a - Heat pump scroll chillers
EWAQ- - R410a - Air-cooled scroll chillers
EWAQ- - R410a - Air-cooled scroll chillers
EWYQ- - R410a - Air-cooled scroll heat pumps
Air and Water cooled scroll chillers & heat pump
Operation
Manual
EWWQ - EWLQ - EWHQ
EWAQ - EWYQ
Air or Water cooled scroll chiller &
heat pump
D-EOMHW00106-15EN
Operation Manual
33
Setpoint/Sub-Menu
Default
Description
Alarm Active
List of the active alarms
Alarm Log
History of all the alarms and acknowledges
Event Log
List of the events
Alarm Snapshot
List of alarm snapshots with all the relevant data recorded at time the alarm occurred.
4.9 Commission Unit
Setpoint/Sub-Menu
Default
Range
Description
Configure Unit
See section 0
Alarm Limits
See Section 4.9.2
Calibrate Unit Sensors
See section 4.9.3
Calibrate Circuit Sensors
See section 4.9.4
Unit Manual Control
See section 0
Circuit 1 Manual Control
See section 0
Circuit 2 Manual Contorl
Scheduled Maintenance
See section 4.9.7
4.9.1 Configure Unit
This page resumes all the specific settings for this unit like unit type, number of circuits, type of
condensing control, etc.. Part of these settings cannot be adjusted and are supposed to be set
during the manufacturing or commissioning of this unit. The modification of each parameter in this
menu requires that the unit switch is set to 0.
Setpoint/Sub-
Menu
Default
Range
Description
Apply Changes=
No
No, Yes
Type yes after changes
Unit Type=
EWWD
EWWD, EWLD
Select the unit type, chiller (EWWD) or condenser less (EWLD) (W/C only)
None
None, Chiller,
HeatPump
Select the unit type basing on the model name.
Noise Class=
Std
Std, Low
Selects between the two noise class. (A/C C/O only)
Number Of Cir=
1
1,2
Number of circuit of the chiller
Inversion Type
No
No, Water, Gas
Type of inversion in heat pump mode. (W/C only)
Cond Ctrl Var=
No
No, Pressure,
Cond In, Cond Out
Enabling of the condensing control (W/C only)
Cond Ctrl Dev=
None
None, Valve, VFD
Select device type used for condensing control (W/C only)
Unit Alm Behavior=
Blinking
Blinking,
NotBlinking
Behavior of the unit alarm digital output
Display Units=
Metric
Metric,English
Measurement system
HMI Language=
English
English
Enable Options
PVM/GFP=
Disable
Disable, Enable
Enabling of the phase voltage monitor
External Alarm=
Disable
Disable, Event,
Alarm
Enabling of the Event or External Alarm input.
Demand Limit=
Disable
Disable, Enable
Enabling of the Demand Limit signal
Lwt Reset=
Disable
Disable, Enable
Enabling of the Lwt Reset signal
Comm Module 1=
None
None, IP, Lon,
MSTP, Modbus,
AWM
Auto-configured when UC link with related module
Comm Module 2=
None
Modbus, Bacnet
IP, Bacnet MSTP,
Lon, AWM
Auto-configured when UC link with related module
Comm Module 3=
None
Modbus, Bacnet
IP, Bacnet MSTP,
Lon, AWM
Auto-configured when UC link with related module
Modification to any of these values will require to be acknowledged to the controller by setting
“Apply Changes = Yes”. This will cause a controller reboot! This action can only be performed with
the Q0 switch on the unit switchbox set to 0.
