D-EOMAC01905-23_01EN- 71/78
String in the alarm list:
CxCmp1 OffMtrAmpsHi
String in the alarm log:
± CxCmp1 OffMtrAmpsHi
String in the alarm snapshot
CxCmp1 OffMtrAmpsHi
Clean condenser coils to allow a lower
condensing pressure (A/C units).
The wrong compressor model has
been selected.
Check the compressor model for this
unit.
Reset
Notes
Local HMI
Network
Auto
5.6.12 High Motor Temperature Alarm
This alarm indicates that the motor temperature has exceeded the maximum temperature limit for safe operations.
Symptom
Cause
Solution
Circuit status is Off.
The compressor does not load
anymore or even unload, circuit is
stopped.
Bell icon is moving on controller’s
display.
String in the alarm list:
CxCmp1 OffMotorTempHi
String in the alarm log:
CxCmp1 OffMotorTempHi
String in the alarm snapshot
CxCmp1 OffMotorTempHi
Insufficient motor cooling.
Check refrigerant charge.
Check if operational envelope of the
unit is respected.
Motor temperature sensor could not
operate properly.
Check the readings of the motor
temperature sensor and check the
Ohmic value. A correct reading should
be around hundreds of Ohm at
ambient temperature.
Check the electrical connection of the
sensor with the electronic board.
Reset
Notes
Local HMI
Network
Auto
5.6.13 High Oil Pressure Differential Alarm
This alarm indicates that the oil filter is clogged and needs to be replaced.
Symptom
Cause
Solution
Circuit status is Off.
The circuit is stopped.
Bell icon is moving on controller’s
display.
String in the alarm list:
CxCmp1 OffOilPrDiffHi
String in the alarm log:
± CxCmp1 OffOilPrDiffHi
String in the alarm snapshot
CxCmp1 OffOilPrDiffHi
Oil filter is clogged.
Replace oil filter.
Oil Pressure Transducer is reading
incorrectly.
Check Oil Pressure Transducer
readings with a gauge.
Condensing Pressure Transducer is
reading incorrectly.
Check Condensing Pressure
Transducer readings with a gauge.
Reset
Notes
Local HMI
Network
Auto
5.6.14 High Pressure alarm
This alarm is generated in case the Condensing saturated temperature rise above the Maximum condensing saturated
temperature and the control is not able to compensate to this condition. The maximum condenser saturated temperature
is 68.5°C but it can decrease when the evaporator saturated temperature become negative.
In case of water-cooled chillers operating at high condenser water temperature, if the Condensing saturated temperature
exceeds the Maximum condenser saturated temperature, the circuit is only switched off without any notification on the
screen as this condition is considered acceptable in this range of operation.
Symptom
Cause
Solution
Circuit status is Off.
The compressor does not load
anymore or even unload, circuit is
stopped.
Bell icon is moving on controller’s
display.
String in the alarm list:
CxCmp1 OffCndPressHi
One or more condenser fans do not
operate properly (A/C units).
Check if fans protections have been
activated.
Check that the fans can turn freely.
Check that there is not any obstacle to
the free ejection of the air blown.
Dirty or partially blocked condenser
coil (A/C units).
Remove any obstacle;
Clean the condenser coil using soft
brush and blower.
