Je bekijkt pagina 60 van 84
Air cooled inverter water chiller
OPERATION
MANUAL
Operation Manual
60
EWAD TZ B 160-700
Air cooled inverter water chiller
D-EOMAC00909-16EN
Symptom
Cause
Solution
Heat Recovery is Off
Bell icon is moving on controller’s
display.
String in the alarm list:
UnitAlHRLvgSen
String in the alarm log:
UnitAlHRLvgSen
String in the alarm snapshot
UnitAlHRLvgSen
Sensor is broken.
Check for sensor integrity.
according table and allowed kOhm
(k) range.
Check correct sensors operation
Sensor is shorted.
Check if sensor is shorted with a
resistance measurement.
Sensor is not properly connected
(open).
Check for absence of water or
humidity on electrical contacts.
Check for correct plug-in of the
electrical connectors.
Check for correct sensors wiring also
according electrical scheme.
6.1.1.7 Switch Box Temperature sensor fault
This alarm is generated any time that the input resistance is out of an acceptable range.
Symptom
Cause
Solution
Heat Recovery is Off
Bell icon is moving on controller’s
display.
Bell icon is moving on controller’s
display.
String in the alarm list:
SwitchBoxTempSen
String in the alarm log:
SwitchBoxTempSen
String in the alarm snapshot
SwitchBoxTempSen
Sensor is broken.
Check for sensor integrity.
according table and allowed kOhm
(k) range.
Check correct sensors operation
Sensor is shorted.
Check if sensor is shorted with a
resistance measurement.
Sensor is not properly connected
(open).
Check for absence of water or
humidity on electrical contacts.
Check for correct plug-in of the
electrical connectors.
Check for correct sensors wiring also
according electrical scheme.
6.1.1.8 Heat Recovery Water Temperatures inverted
This alarm is generated any time that the heat recovery entering water temperature is lower than
the leaving by 1°C and at least one compressor is running.
Symptom
Cause
Solution
Bell icon is moving on controller’s
display.
Bell icon is moving on controller’s
display.
String in the alarm list:
Unit HRInvAl
String in the alarm log:
Unit HRInvAl
String in the alarm snapshot
Unit HRInvAl
Entering and leaving water
temperature sensors are inverted.
Check cabling of the sensors on the
unit controller.
Check offset of the two sensors with
the water pump running
Entering and leaving water pipes are
reversed
Check if the water flows in counter
flow respect to refrigerant.
Water pump operate reverse.
Check if the water flows in counter
flow respect to refrigerant.
6.1.1.9 Bad Demand Limit Input
This alarm is generated when the Demand Limit option has been enabled and the input to the
controller is out of the admitted range.
Symptom
Cause
Solution
