Air cooled inverter water chiller
OPERATION
MANUAL
Operation Manual
58
EWAD TZ B 160-700
Air cooled inverter water chiller
D-EOMAC00909-16EN
6 Alarms
The UC protects the unit and the components from operating in abnormal conditions. Protections
can be divided in preventions and alarms. Alarms can then be divided in pump-down and rapid
stop alarms. Pump-down alarms are activated when the system or sub-system can perform a
normal shutdown in spite of the abnormal running conditions. Rapid stop alarms are activated
when the abnormal running conditions require an immediate stop of the whole system or sub-
system to prevent potential damages.
The UC displays the active alarms in a dedicated page and keep an history of the last 50 entries
divided between alarms and acknowledges occurred. Time and date for each alarm event and of
each alarm acknowledge are stored.
The UC also stores alarm snapshot of each alarm occurred. Each item contains a snapshot of the
running conditions right before the alarm has occurred. Different sets of snapshots are
programmed corresponding to unit alarms and circuit alarms holding different information to help
the failure diagnosis.
6.1.1 Unit Warning Alarms
6.1.1.1 Rapid Recovery Module Communication Fail
This alarm is generated in case of communication problems with the RRC module.
Symptom
Cause
Solution
Bell icon is moving on controller’s
display.
String in the alarm list:
RpdRcvryCommFail
String in the alarm log:
RpdRcvryCommFail
String in the alarm snapshot
RpdRcvryCommFail
Module has no power supply
Check the power supply from the
connector on the side of the module.
Check if LEDs are both green.
Check if the connector on the side is
tightly inserted in the module
Module address is not properly set
Check if module’s address is correct
referring to the wiring diagram.
Module is broken
Check if LED are on and both green.
If BSP LED is solid red replace the
module
Check if power supply is ok but LEDs
are both off. In this case replace the
module
6.1.1.2 Fan Alarm Module Communication Fail
This alarm is generated in case of communication problems with the FAC module.
Symptom
Cause
Solution
Bell icon is moving on controller’s
display.
String in the alarm list:
FanMdlCommFail
String in the alarm log:
FanMdlCommFail
String in the alarm snapshot
FanMdlCommFail
Module has no power supply
Check the power supply from the
connector on the side of the module.
Check if LEDs are both green.
Check if the connector on the side is
tightly inserted in the module
Module address is not properly set
Check if module’s address is correct
referring to the wiring diagram.
Module is broken
Check if LED are on and both green.
If BSP LED is solid red replace the
module
Check if power supply is ok but LEDs
are both off. In this case replace the
