Je bekijkt pagina 39 van 84
Air cooled inverter water chiller
OPERATION
MANUAL
EWAD TZ B 160-700
Air cooled inverter water chiller
D-EOMAC00909-16EN
Operation Manual
39
Test Fan 2=
Off
Off/On
Test of the Fan Output #2
Test Fan 3=
Off
Off/On
Test of the Fan Output #3
Test Fan 4=
Off
Off/On
Test of the Fan Output #4
Test Fan 5=
Off
Off/On
Test of the Fan Output #5
Test Fan 6=
Off
Off/On
Test of the Fan Output #6
Test Var VR=
Off
Off/On
Test of VR3 slide position
Test VR Load=
Off
Off/On
Test of VR Load relay (VR3)
Test VR Unld=
Off
Off/On
Test of VR Unload relay (VR2)
Test VFD Speed=
0%
0-100%
Test of the VFD for fans
Test EXV Pos=
0%
0-100%
Test of the Expansion Valve movements
Test EcoEXV Pos=
0%
0-100%
Test Of the Economizer Expansion Valve movements
Input/Output Values
Cir Sw Inpt=
Off
Off/On
Status of the Circuit Enable switch
Mhp Sw Inpt=
Off
Off/On
Status of the Mechanical High Pressure switch
Gas Leak Inpt=
Off
Off/On
Status of the Gas Leak switch
Fan Alm Inpt=
Off
Off/On
Status of the Fan Alarm Input
Evap Pr Inpt=
0.0V
0.4-4.6V
Input voltage for the Evaporator Pressure
Cond Pr Inpt=
0.0V
0.4-4.6V
Input voltage for the Condenser Pressure
Oil Pr Inpt=
0.0V
0.4-4.6V
Input voltage for the Oil Pressure
Gas Leak Inpt=
0.0V
0.0-10.0V
Input voltage for the Gas Leak sensor
Econ Pr Inpt=
0.0V
0.4-4.6V
Input voltage for the Economizer Pressure
Econ Temp Res=
0.0Ohm
340-300kOhm
Resistance of the Economizer Temp sensor
Suct Temp Res=
0.0Ohm
340-300kOhm
Resistance of the Suction Temp sensor
Disc Temp Res=
0.0Ohm
340-300kOhm
Resistance of the Discharge Temp sensor
Strtr Outpt=
Off
Off/On
Status of the Inverter start command
Liq Inj Outpt=
Off
Off/On
Status of the Liquid Line SV relay
Econ Sv Outpt=
Off
Off/On
Status of the Economizer SV relay
Fan 1 Outpt=
Off
Off/On
Status of the Fan Output #1
Fan 2 Outpt=
Off
Off/On
Status of the Fan Output #2
Fan 3 Outpt=
Off
Off/On
Status of the Fan Output #3
Fan 4 Outpt=
Off
Off/On
Status of the Fan Output #4
Fan Vfd Outpt=
0.0V
0-10.0V
Output voltage to the fan VFD
Variable VR St
Off(VR2)
Off(VR2)/On(VR3)
Variable VR slide position (VR2, VR3)
4.11.5 Scheduled Maintenance
This page may contains the contact number of the Service organization taking care of this unit and
the next maintenance visit schedule.
Setpoint/Sub-Menu
Default
Range
Description
Next Maint=
Jan 2015
Schedule date for next maintenance
Support Reference=
999-999-999
Reference number or email of Service Org
4.11.6 Setup for communication modules
In order to properly setup the communication modules (Modbus, Bacnet IP, Bacnet MSTP and
LON), please refer to the related documentation available from the factory.
4.12 About this Chiller
This page resumes all the information needed to identify the unit and the current software version
installed. These information may be required in case of alarms or unit failure
Setpoint/Sub-Menu
Default
Range
Description
Model
Unit model and code name
Unit S/N=
Unit serial number
OV14-00001
BSP Ver=
Firmware version
App Ver=
Software version
