Air cooled inverter water chiller
OPERATION
MANUAL
EWAD TZ B 160-700
Air cooled inverter water chiller
D-EOMAC00909-16EN
Operation Manual
35
description of the alarms and how to handle will be discussed in the section Troubleshooting this
chiller.
Setpoint/Sub-Menu
Default
Description
Alarm Active
List of the active alarms
Alarm Log
History of all the alarms and acknowledges
Event Log
List of the events
Alarm Snapshot
List of alarm snapshots with all the relevant data recorded at time the alarm occurred.
4.11 Commission Unit
Setpoint/Sub-Menu
Default
Range
Description
Configuration
-
Submenus for Unit and Circuit configuration
Alarms Limits
-
Submenu for alarm limits definition
Calibrate Sensors
-
Submenus for Unit and Circuit sensor calibration
Manual Control
-
Submenus for Unit and Circuit manual control
Scheduled Maintenance
-
Submenu for scheduled maintenance
4.11.1 Configuration
Setpoint/Sub-Menu
Default
Range
Description
Unit
-
Submenu for Unit configuration
Circuit #1
-
Submenu for Circuit 1 configuration
Circuit #2
-
Submenu for Circuit 2 configuration
4.11.1.1 Unit Configuration
This page resumes all the specific settings for this unit like number of circuits, compressors type,
fan regulation strategy, etc. Part of these settings cannot be adjusted and are supposed to be set
during the manufacturing or commissioning of this unit. See chapter “Commission Unit” for more
details.
Setpoint/Sub-
Menu
Default
Range
Description
Apply Changes=
No
No, Yes
Type yes after changes
Unit Type
EWAD TZ
B
EWAD TZ, EWAD TZ B
Number Of Ckts=
2
1,2
Comp Type=
None
Not Set; 3120; 3122; F3AL; F3AS
Set compressor model
Comp Motor
Type=
AC
AC, DC
Define the motor type
AC for Brushed motor
DC for Brushless motor
Cond Cntrl=
Step
Step, Vfd, SpdTrl
Set condenser fan control
Fan Type=
AC700
AC900, AC900L, AC700, EC900,
EC900L, EC700, EC1000L
Fan type
Pump Type=
On-Off
On-Off, Fixed Speed, VPF
Set Pump Control
Load PD Sns=
None
0-10V, 4-20mA,BMS,None
Set Load Pressure Drop Sensor Type
Power Supply=
400V/50-
60Hz
400V/50-60Hz
415V/50Hz
440V/60Hz
460V/60Hz
380V/50-60Hz
Define the power supply
Energy Mtr=
None
None, Nemo D4-L; Nemo D4-Le
Set Energy Meter Type
Leak Detector=
None
None, Digital, Analog
Set the leak detector type
Comm Module
1=
None
Modbus, Bacnet IP, Bacnet MSTP, Lon,
AWM
Comm Module
2=
None
Modbus, Bacnet IP, Bacnet MSTP, Lon,
AWM
Comm Module
3=
None
Modbus, Bacnet IP, Bacnet MSTP, Lon,
AWM
Fan Alarm
No
No, Yes
Enable of the function Fan Alarm
Switch Box Tem=
No
No, Yes
Enable of the Switch Box Temperature
Rapid Restart=
Off
Off,On
Enable of the Rapid Restart
Alm Out Type=
Solid
Solid, Blinking
Define the behavior of the alarm output
Loc Net Switch=
No
No,Yes
Enable of the local network switch
M/S Address=
None
None; Master; Slave 1; Slave 2; Slave 3
Select the unit address in the Master Slave system.
