Air cooled inverter water chiller
OPERATION
MANUAL
Operation Manual
36
EWAD TZ B 160-700
Air cooled inverter water chiller
D-EOMAC00909-16EN
Select none if the unit works as standalone
M/S Num Of
Units=
2
2,3,4
Select the number of units in the Master Slave system
M/S Sns Type
NTC10K
None,NTC10K,PT1000
Select the sensor type used to measure the Master
Slave common leaving water temperature
Display Units=
Metric
Metric, English
Language
English
-
Check for availability of your own language
Modification to any of these values will require to be acknowledged to the controller by setting
“Apply Changes = Yes”. This will cause a controller reboot! This action can only be performed with
the Q0 switch on the unit switchbox set to 0.
4.11.1.2 Circuit Configuration
This page allows to adjust the number of fans for each circuit.
Setpoint/Sub-Menu
Default
Range
Description
Apply Changes=
No
No, Yes
Comp Freq
-
Compressor 3120:
55 Hz; 60 Hz; 65 Hz;
70 Hz
Compressor 3122:
60 Hz; 65 Hz; 70 Hz;
75 Hz; 80 Hz; 85 Hz;
90 Hz
Compressor F3AL:
60 Hz; 65 Hz; 70 Hz;
75Hz; 80 Hz; 85 Hz
Compressor F3AS:
60 Hz; 67,5 Hz; 70 Hz;
75 Hz
Maximum compressor frequency
C1 # Of Fans=
6
Number of fans available.
Heat Recovery=
Disable
Disable, Enable
4.11.2 Alarm Limits
This page contains all alarm limits, including low pressure alarm prevention thresholds. In order to
ensure proper operation they have to be set manually according to the specific application.
Setpoint/Sub-Menu
Default
Range
Description
Low Press Hold=
180.0kPa
Low pressure safety limit to stop capacity increase
Low Press Unld=
160.0kPa
Low pressure alarm prevention
Hi Oil Pr Dly=
30s
Delay for the High oil pressure difference alarm
Hi Oil Pr Diff=
250kPa
Pressure drop for a clogged filter
Hi Disch Temp=
110.0°C
Maximum discharge temperature limit
Hi Cond Pr Dly=
5s
Delay on the High pressure alarm from transducer
Lo Pr Ratio Dly=
90s
Delay on the low pressure ratio alarm
OAT Lockout=
4.0°C
Air temperature operational limit
Strt Time Lim=
60s
Time limit for the low ambient start
Evap Water Frz=
2.2°C
Freeze protection limit
Evap Flw Proof=
15s
Flow proof delay
Evp Rec Timeout=
3min
Recirculating timeout before the alarm is raised
Low DSH Limit=
12.0°C
Minimum acceptable discharge superheat
Gas Conc Lim=
200ppm
Maximum gas concentration limit
HP Sw Test C#1
Off
On, Off. Enables to check operation of the high pressure switch on #1.
HP Sw Test C#2
Off
On, Off. Enables to check operation of the high pressure switch on #2.
Ext Fault Cfg=
Event
Event, Alarm
Definition of the unit behavior after switching of external alarm contact
The HP Sw Test shuts off all fans while compressor is running in order to raise condenser pressure
until tripping of the high pressure switches. Beware that in case of high pressure switch failure the
safety valves will trip and hot refrigerant will be ejected at high pressure!
Once tripped, the software will get back to normal operation. However, the alarm will not be reset
until the high pressure switches are manually reset through the button included in the switch.
