Air cooled inverter water chiller
OPERATION
MANUAL
Operation Manual
34
EWAD TZ B 160-700
Air cooled inverter water chiller
D-EOMAC00909-16EN
Evap LWT=
-273.1°C
-
Controlled water temperature
Evap EWT=
-273.1°C
-
Return water temperature
Evap Delta T=
-273.1°C
-
Delta T across Evaporator
Pulldn Rate=
0.0°C/min
-
Rate of decrease of the controlled temperature
Outside Air=
-273.1°C
-
Outside air temperature
Switch Box T=
-273.1°C
-
Switch Box temperature
Common LWT=
-273.1°C
-
Master Slave Common supply water temperature
HR LWT=
-273.1°C
Heat Recovery Leaving Water Temperature
HR EWT=
-273.1°C
Heat Recovery Entering Water Temperature
4.6 Unit Capacity
This page displays the actual unit and circuit capacity
Setpoint/Sub-Menu
Default
Range
Description
Unit=
-
-
Actual unit capacity
Circuit #1=
-
-
Actual circuit 1 capacity
Circuit #2=
-
-
Actual circuit 2 capacity
4.7 Unit Mode
Menu to select the available unit modes
Setpoint/Sub-Menu
Default
Range
Description
Available Modes=
Cool
Cool,
Cool w/ Glycol,
Cool/Ice w/ Glycol,
Ice w/ Glycol,
Test
Available operating modes
4.8 Unit Enable
This page allows to enable or disable unit and circuits. For the unit it also possible enable the
operation with time scheduler, while for circuit it is possible to enable the test mode.
Setpoint/Sub-Menu
Default
Range
Description
Unit
Enable
Enable, Disable, Scheduler
Unit enable command
Circuit #1
Enable
Enable, Disable, Test
Circuit #1 enable command
Circuit #2
Enable
Enable, Disable, Test
Circuit #2 enable command
4.9 Timers
This page indicates the remaining cycle timers for each circuit and the remaining staging timers.
When the cycle timers are active any new start of a compressor is inhibited.
Setpoint/Sub-Menu
Default
Range
Description
C1 Cycle Tm Left=
0s
-
Circuit 1 cycle timer
C2 Cycle Tm Left=
0s
-
Circuit 2 cycle timer
C1 Cycle Tmr Clr=
Off
Off, On
Clear circuit 1 cycle timer
C2 Cycle Tmr Clr=
Off
Off, On
Clear circuit 2 cycle timer
Stg Up Dly Rem=
0s
-
Remaining delay to next compressor start
Stg Dn Dly Rem=
0s
-
Remaining delay to next compressor stop
Clr Stg Delays=
Off
Off, On
Clear remaining delays to next compressor start/stop
Ice Cycle Rem=
0min
-
Remaining Ice cycle delay
Clr Ice Dly
Off
Off, On
Clear remaining delay for Ice mode
4.10 Alarms
This link jumps to the same page accessible with the Bell button. Each of the items represents a
link to a page with different information. The information shown depends on the abnormal
operating condition that caused the activation of unit, circuit or compressor safeties. A detailed
