Je bekijkt pagina 26 van 84
Air cooled inverter water chiller
OPERATION
MANUAL
Operation Manual
26
EWAD TZ B 160-700
Air cooled inverter water chiller
D-EOMAC00909-16EN
Speed 1=
80%
0-100%
Speed when the input Double Speed Switch is open
Speed 2=
60%
0-100%
Speed when the input Double Speed Switch is close
Thermo Off Speed=
50%
0-100%
Speed when there are no compressors running
Plant PD=
-
-
Actual Plant Pressure Measurements
Plant PD Sp=
0kPa
0-1000kPa
Plant Pressure Drop Setpoint
Evap PD=
-
-
Actual Evaporator Pressure Drop Measurements
Min Evap PD=
0kPa
0-1000kPa
Minimum Evaporator Pressure Drop setpoint
Hysteresis
0kPa
0-1000kPa
Hysteresis value for bypass value
Pump Speed=
-
-
Actual Pump Speed
Min Speed=
0%
0-100%
Minimum Pump Speed
Max Speed=
100%
0-100%
Maximum Pump Speed
Mode=
Auto
Auto-Manual
Pump mode
Manual Speed=
0%
0-100%
Manual Pump Speed
Sns Scale=
200kPa
0-2000kPa
Plant Pressure Drop Sensor Scale
Bypass
Open
Open,Close
Bypass valve state
4.2.5 Master/Slave
All data and parameters available in this sub-menus are related to the Master Slave function. Refer
to Master Slave manual for more details.
Setpoint/Sub-
Menu
Default
Range
Description
Data
-
Submenu Data. This link is available only on the Master unit
Options
-
Submenu Options. This link is available only on the Master unit
Thermostat Ctrl
-
Submenu Thermostat Ctrl. This link is available only on the Master unit
Timers
-
Submenu Timers. This link is available only on the Master unit
Standby Chiller
-
Submenu Standby Chiller. This link is available only on the Master unit
Disconnect Unit
No
No,Yes
Parameter to disconnect the unit by the Master Slave system.
When this parameter is set to Yes the unit follows all local settings.
4.2.5.1 Data
In this menu are collected all main data related to Master Slave function.
Setpoint/Sub-
Menu
Default
Range
Description
Next On=
-
-,Master, Slave 1, Slave 2,
Slave 4
Display next chiller that will be starts
Next Off=
-
-,Master, Slave 1, Slave 2,
Slave 4
Display next chiller that will be stopped
Standby=
-
-,Master, Slave 1, Slave 2,
Slave 4
Display the actual standby chiller
Switch Date
-
dd/mm/yyyy
Display the day in which the standby chiller will be cycled
Switch Time
-
hh:mm:ss
Display at which time of the switch day the standby chiller will be
cycled
Plan Load=
-
0%...100%
Display the actual plant load
Avg EWT
-
-
Display the actual average entering water temperature value
Mst State=
-
Off, On, Alarm, Comm Err
Display the actual state of the Master
Sl1 State=
-
Off, On, Alarm, Comm Err
Display the actual state of the Slave 1
Sl2 State=
-
Off, On, Alarm, Comm Err
Display the actual state of the Slave 2
Sl3 State=
-
Off, On, Alarm, Comm Err
Display the actual state of the Slave 3
Mst Standalone=
-
No, Yes
Display if the standalone mode if active on the Master
Sl1 Standalone
-
No, Yes
Display if the standalone mode if active on the Slave 1
Sl2 Standalone
-
No, Yes
Display if the standalone mode if active on the Slave 2
Sl3 Standalone
-
No, Yes
Display if the standalone mode if active on the Slave 3
Mst Load=
-
0%...100%
Display the actual load of the Master
Sl1 Load=
-
0%...100%
Display the actual load of the Slave 1
Sl2 Load=
-
0%...100%
Display the actual load of the Slave 2
Sl3 Load=
-
0%...100%
Display the actual load of the Slave 3
Mst LWT=
-
-
Display the Master leaving water temperature
Sl1 LWT=
-
-
Display the Slave1 leaving water temperature
Sl2 LWT=
-
-
Display the Slave2 leaving water temperature
Sl3 LWT=
-
-
Display the Slave3 leaving water temperature
Mst EWT=
-
-
Display the Master entering water temperature
