Air cooled inverter water chiller
OPERATION
MANUAL
Operation Manual
22
EWAD TZ B 160-700
Air cooled inverter water chiller
D-EOMAC00909-16EN
The Remote can be ordered with the unit and shipped loose as a field installed option. It can also
be ordered any time after chiller shipment and mounted and wired on the job as explained on the
following page. The remote panel is powered from the unit and no additional power supply is
required.
All viewing and setpoint adjustments available on the unit controller are available on the remote
panel. Navigation is identical to the unit controller as described in this manual.
The initial screen when the remote is turned on shows the units connected to it. Highlight the
desired unit and press the wheel to access it. The remote will automatically show the units
attached to it, no initial entry is required.
The Remote HMI can be extended up to 700m using the process bus connection available on the
UC. With a daisy-chain connection as below, a single HMI can be connected to up to 8 units. Refer
to the specific HMI manual for details.
3.8 Embedded Web Interface
The MicroTech III controller has an embedded web interface that can be used to monitor the unit
when connected to a local network. It is possible to configure the IP addressing of the MicroTech III
as a fixed IP of DHCP depending on the network configuration.
With a common web browser a PC can connect with the unit controller entering the IP address of
the controller or the host name, both visible in the “About Chiller” page accessible without entering
a password.
When connected it will be required to enter a user name and a password as shown in the picture
below:
Enter the following credential to get access to the web interface:
User Name: ADMIN
Password: SBTAdmin!
The following page will be displayed:
