D–EOMCP00104-14EN - 8/82
4. SYSTEM ARCHITECTURE
The modular architecture is based on the use of the ASDU01C Series control.
In particular, a base controller (large version, built-in display, or, optionally, semi graphical
additional display) is used to control the basic unit functions and to manage the first two
compressors; a second controller (large version) is used to manage the third and fourth compressor
if they are present.
Several, up to four for each controller, controller expansion board are used to add optional
features to the control.
Drivers for electronic expansion valve are foreseen as an optional feature.
The overall architecture is shown in fig. 1
pCO2 controller #1
pCO2 controller #2
EEXV Driver
#1
EEXV Driver
#2
EEXV Driver
#3
EEXV Driver
#4
Additional
Display
pLAN
pCOe
Expansion #1
pCOe
Expansion #2
pCOe
Expansion #3
pCOe
Expansion #4
J23 port
pCOe
Expansion #4
J23 port
Supervisory
Systems
pLAN
pLAN
pLAN
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
pCOe
Expansion #2
pCOe
Expansion #1
Fig. 1 - Architecture
Electronic expansion valves drivers and the additional display are connected using pLAN
network of ASDU01Ccontrols while pCO
e
expansion boards are connected to ASDU01C
controllers using the RS485 network dedicated to expansion.
