Table 3 - Compressors unloading and shutdown management (4 compressors unit)
Step n. Leader Comp. Lag 1 Comp. Lag 2 Comp. Lag 3 Comp.
0 100% 100% 100% 100%
1 Fixed at 100% Fixed at 100% Fixed at 100% Unload up to 75%
2 Fixed at 100% Fixed at 100% Unload up to 75% Fixed at 75%
3 Fixed at 100% Unload up to 75% Fixed at 75% Fixed at 75%
4 Unload up t75% Fixed at 75% Fixed at 75% Fixed at 75%
5 Fixed at 75% Fixed at 75% Fixed at 75% Unload up to 50%
6 Fixed at 75% Fixed at 75% Unload up to 50% Fixed at 50%
7 Fixed at 75% Fixed at 75% Fixed at 50% Unload up to 25%
8
If T is approaching SetP
… Waiting …
9a
SetP-RDT<T< SetP-RDT
Fixed at 75% Fixed at 75% Load up to 75% Stop
9b
SetP-RDT<T or T> SetP-RDT
Fixed at 75% Fixed at 75% Fixed at Stop
10
(if lag2 at 75%)
Fixed at 75% Fixed at 75% Fixed at Off
11 Fixed at 75% Unload up to 50% Fixed at 50% Off
12 Fixed at 75% Fixed at 50% Fixed at 25% Off
13
If T is approaching SetP
… Waiting …
14a
SetP-RDT<T< SetP-RDT
Fixed at 75% Load up to 75% Stop Off
14b
SetP-RDT<T or T> SetP-RDT
Fixed at 75% Fixed at 50% Stop Off
15
( if lag1 at 75%)
Fixed at 75% Unload up to 50% Off Off
16 Unload up to 50% Fixed at 50% Off Off
17 Fixed at 50% Unload up to 25% Off Off
18
If T is approaching SetP
… Waiting …
19a
SetP-RDT<T< SetP-RDT
Load up to 75% Stop Off Off
19b
SetP-RDT<T or T> SetP-RDT
Fixed at 50% Stop Off Off
20 Unload up to 25% Off Off Off
21
If T is approaching SetP
… Waiting …
22
If (SetP - T) < Shutdown DT & Cooling
or (T – SetP) < Shutdown DT & Heating
….Wait….
23 Stop Off Off Off
24 Off Off Off Off
