D–EOMCP00104-14EN - 21/82
Analog Output
Digital Output
Ch.
Description Type
Ch. Description
AO1
Heat Recovery Bypass valve (*) 4-20mA DO1 4 Way valve HR #1
DO2 4 Way valve HR #2
DO3 4 Way valve HR #3
DO4 4 Way valve HR #4
(*) Optional
5.4.2. Heat pump option
5.4.2.1. Expansion connected to ASDU01C #1
Analog Input
Digital Input
Ch.
Description Type
Ch. Description
B1 Ambient temperature sensor
NTC
DI1 Heating/Cooling Switch
B2 Defrost Sensor #1 (*)
NTC
DI2 SPARE
B3 Defrost Sensor #2 (*)
NTC
DI3 SPARE
B4 SPARE DI4 SPARE
Analog Output
Digital Output
Ch. Description Type
Ch. Description
AO1 Heat Pump Bypass valve 4-20mA DO1 4 Way valve Comp #1
DO2 Suction liquid injection #1
DO3 4 Way valve Comp #2
DO4 Suction liquid injection #2
(*) In case EEXV driver is not installed. If EEXV driver is installed, defrost temperature should be detected through
EEXV driver (suction temperature).
(**) Optional
5.4.2.2. Expansion connected to ASDU01C #2
Analog Input
Digital Input
Ch.
Description Type
Ch. Description
B1 SPARE
NTC
DI1 SPARE
B2 Defrost Sensor #3 (*)
NTC
DI2 SPARE
B3 Defrost Sensor #4 (*)
NTC
DI3 SPARE
B4 SPARE DI4 SPARE
Analog Output
Digital Output
Ch. Description Type
Ch. Description
AO1 SPARE 4-20mA DO1 4 Way valve Comp #3
DO2 Suction liquid injection #3
DO3 4 Way valve Comp #4
DO4 Suction liquid injection #4
(*) In case EEXV driver is not installed. If EEXV driver is installed, defrost temperature should be detected through
EEXV driver (suction temperature).
5.5. pCO
e
expansion #3 – Water pump control
Analog Input
Digital Input
Ch. Description Type
Ch. Description
B1 SPARE DI1 First pump Alarm
B2 SPARE DI2 Second pump Alarm
B3 SPARE DI3 First HR pump Alarm (*)
