8 | Electrical installation
Installer reference guide
104
EPRA14~18DAV3+W1 + ETBH/X16DA6V+9W
Daikin Altherma 3 H HT W
4P587501-1A – 2020.01
Item Description
WLAN adapter See:
▪ Installation manual of the WLAN adapter
▪ Addendum book for optional equipment
Use the cable delivered with the WLAN
adapter.
[D] Wireless gateway
LAN adapter See:
▪ Installation manual of the LAN adapter
▪ Addendum book for optional equipment
Wires: 2×(0.75~1.25mm²). Must be
sheathed.
Maximum length: 200m
See below ("LAN adapter – System
requirements").
LAN adapter – System requirements
The requirements posed on the system depend on the LAN adapter application/
system layout (app control, or Smart Grid application).
App control:
Item Requirement
LAN adapter software It is recommended to ALWAYS keep the LAN adapter
software up-to-date.
Unit control method On the user interface, make sure to set [2.9]=2
(Control = Room thermostat)
Smart Grid application:
Item Requirement
LAN adapter software It is recommended to ALWAYS keep the LAN adapter
software up-to-date.
Unit control method On the user interface, make sure to set [2.9]=2
(Control = Room thermostat)
Domestic hot water
settings
To allow for energy buffering in the domestic hot
water tank, on the user interface, make sure to set
[9.2.1] (Domestic hot water) to one of the
following:
▪ EKHWS/E
Tank with booster heater installed at the side of the
tank.
▪ EKHWP/HYC
Tank with optional booster heater installed at the
top of the tank.
