Installation manual
19
ERSQ+ERRQ011~016AAV1+Y1
Outdoor unit for air to water heat pump
4PW49635-1C
13. DISPOSAL REQUIREMENTS
Dismantling of the unit, treatment of the refrigerant, of oil and of other
parts must be done in accordance with relevant local and national
legislation.
14. UNIT SPECIFICATIONS
Technical specifications
Electrical specifications
NOTES
Model
011 014 016
Casing material Painted galvanised steel
Dimensions h x w x d
(mm)
1345 x 900 x 320 1345 x 900 x 320 1345 x 900 x 320
Weight
(kg)
120 120 120
Operation range
• heating (min./max) (°C)
–20/20 –20/20 –20/20
• domestic hot water
(min./max)
(°C)
–20/35 –20/35 –20/35
Refrigerant oil
Daphne FVC68D Daphne FVC68D Daphne FVC68D
Piping connection
• liquid (mm)
9.52 9.52 9.52
• gas (mm)
15.9 15.9 15.9
Model
011 014 016
V1 Y1 V1 Y1 V1 Y1
Phase 1N~ 3N~ 1N~ 3N~ 1N~ 3N~
Frequency
(Hz)
50 50 50
Voltage range
• minimum (V)
220/380 220/380 220/380
• maximum (V)
240/415 240/415 240/415
Nominal running current (A) 15.9 5.3 20.2 6.77 22.2 7.79
