13 Special requirements for R32 units
Installation and operation manual
23
ERA200~300AMYFB
Inverter outdoor unit for AHU option kit and air curtains
4P780153-1 – 2024.07
Overview: flowchart
Start installation
No safety measure
Alarm
Natural ventilation
Remote controller with R32 safety system compatibility shall be
installed for the compatible air curtain. See the requirements in
above text.
Do NOT use 'Alarm' as the ONLY safety measure in case the air
curtain is installed in an occupied space where people are
restricted in their movement.
Combine or use another safety measure.
Is the air curtain installed in occupancy:
1. with sleeping facilities?
2. where an uncontrolled number of people are present?
3. accessible for persons not familiar with the necessary safety
precautions?
4. where people are restricted in their movement.
Make field settings in the
indoor unit accordingly.
Alarm system must additionally
warn at a supervised location
with 24-hour monitoring.
YES
NO
Is one (or more) of the
above conditions met?
Not allowed!
Determine other safety
measure.
Determine total room area (= total area of the space with natural
ventilation and the space in which the air curtain is installed).
The partition between two rooms on the same floor MUST meet
one of the two requirements for natural ventilation.
Derive total refrigerant charge limit.
NO
YES
Total charge amount
<
Total charge limit
A
1
+ A
[m²]
Total charge limit [kg]
See Step
1 in above chapter
See Step
2 in above chapter
See Step
4 in above chapter
Note: The flowchart is an overview. Always refer to the full text mentioned in this manual for clear understanding and detailed explanation.
13.2 Requirements for air handling
units
For special R32 requirements in case of an AHU connection, refer to
the EKEA installation and operation manual.
