2 User safety instructions
Operation manual
3
EPVX10+14S(U)18+23A + EPBX10~14A
Daikin Altherma 4 H F+W
4P773378-1 – 2024.11
Breadcrumbs
Breadcrumbs (example: [3.1]) help you to locate where you are in
the menu structure of the user interface.
1 To enable the breadcrumbs: swipe left from the home screen,
then tap Settings.
Under Settings > Breadcrumbs you can switch breadcrumbs
ON:
Breadcrumbs
2 To disable the breadcrumbs: navigate to the location as
described above, and switch breadcrumbs OFF:
Breadcrumbs
This document also mentions these breadcrumbs. Example:
1 Go to [3.1]: Space heating/cooling > Operation range.
This means:
1 Starting from the home screen, swipe left and tap Space
heating/cooling.
Malfunctioning
Main zone
Additional zone
Space heating/
cooling
Domestic hot
water
Settings
Information
Commissioning
08:30
25
February
2025
11 -
1 - 2 - 3 -
4 - 5 - 6 -
7 -
2 Tap Operation range. The breadcrumb (if breadcrumb
setting is ON) is visible at the left side of the Operation range
label.
Space heating/cooling
Operation range
Emergency selection
Operation mode schedule
Overshoot
Operation mode
Antifrost
Additional zone
Pump limitation maintenance
mode
3.7 -
3.3 -
3.5 -
3.1 -
3.2 -
3.4 -
3.6 -
3.8 -
2 User safety instructions
Always observe the following safety instructions and regulations.
2.1 General
WARNING
If you are NOT sure how to operate the
unit, contact your installer.
WARNING
This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved.
Children SHALL NOT play with the
appliance.
Cleaning and user maintenance
SHALL NOT be made by children
without supervision.
WARNING
To prevent electrical shocks or fire:
▪ Do NOT rinse the unit.
▪ Do NOT operate the unit with wet
hands.
▪ Do NOT place any objects containing
water on the unit.
CAUTION
▪ Do NOT place any objects or
equipment on top of the unit.
▪ Do NOT sit, climb or stand on the
unit.
▪ Units are marked with the following symbol:
This means that electrical and electronic products may NOT be
mixed with unsorted household waste. Do NOT try to dismantle
the system yourself: dismantling the system, treatment of the
refrigerant, of oil and of other parts MUST be done by an
authorised installer and MUST comply with applicable legislation.
Units MUST be treated at a specialised treatment facility for reuse,
recycling and recovery. By ensuring this product is disposed of
correctly, you will help to prevent potential negative consequences
for the environment and human health. For more information,
contact your installer or local authority.
▪ Batteries are marked with the following symbol:
This means that the batteries may NOT be mixed with unsorted
household waste. If a chemical symbol is printed beneath the
symbol, this chemical symbol means that the battery contains a
heavy metal above a certain concentration.
Possible chemical symbols are: Pb: lead (>0.004%).
Waste batteries MUST be treated at a specialised treatment
facility for reuse. By ensuring waste batteries are disposed of
correctly, you will help to prevent potential negative consequences
for the environment and human health.
