EMRQ8~16ABY1
Daikin Altherma outdoor unit
4P501819-1 – 2017.08
Installation manual
30
17.3. Procedure for checking maximum concentration
Check the maximum concentration level in accordance with steps 1
to 4 below and take whatever action is necessary to comply.
1 Calculate the amount of refrigerant (kg) charged to each system
separately.
2 Calculate the volume of the room (m
3
) where the indoor unit is
installed.
3 Calculating the refrigerant density using the results of the
calculations in steps 1 and 2 above.
If the result of the above calculation exceeds the maximum
concentration level, a ventilation opening to the adjacent room
shall be made.
Calculate the refrigerant density taking the volume of the room
where the indoor unit is installed and the adjacent room.
Install ventilation openings in the door of adjacent rooms until
the refrigerant density is smaller than the maximum
concentration level.
18. DISPOSAL REQUIREMENTS
Dismantling of the unit, treatment of the refrigerant, of oil and of other
parts must be done in accordance with relevant local and national
legislation.
19. UNIT SPECIFICATIONS
Technical specifications
Electrical specifications
amount of
refrigerant in a
single unit system
(amount of
refrigerant with
which the system
is charged before
leaving the factory)
+
additional charging
amount (amount of
refrigerant added
locally in
accordance with
the length or
diameter of the
refrigerant piping)
=
total amount of
refrigerant (kg) in
the system
total volume of
refrigerant in the
refrigerant system
size (m
3
) of room in
which indoor unit is
installed
≤
maximum concentration level
(kg/m
3
)
EMRQ 8 10 12 14 16
Casing material painted galvanised steel
Dimensions (hxwxd)
(mm)
1680x1300x765
Weight
(kg)
331 331 331 339 339
Operation range
• Domestic hot water
(min./max.)
(°C)
–20/35
Refrigerant type R410A
Refrigerant oil Daphne FVC68D
Piping connection
• Liquid (mm)
9.52 9.52 12.7 12.7 12.7
• Discharge (mm)
15.9 19.1 19.1 22.2 22.2
EMRQ 8 10 12 14 16
Phase 3N~
Frequency
(Hz)
50
Voltage
(V)
380~415
Voltage range
• Minimum (V)
342
• Maximum (V)
440
Recommended fuses
(A)
20 25 25 40 40
4PEN501819-1.book Page 30 Wednesday, September 13, 2017 12:52 PM
