8 | Wiring diagram
Application Guide
31
EKRACP* + EKRCTR* + EKRMIB* + EKRRVA* + EKRSEN* + EKRSIB* +
EKRUFH*
Daikin Home Controls
4P701747-1A – 2023.10
Underfloor heating or combination of underfloor heating and radiator
4D143269
MULTI IO BOX
A2P
1.1
3.1
1.2
2.1
2.2
3.2
4.1
4.2
5.1
5.2
6.1
6.2
INDOOR
PE
N
L
N
A1
A2
K1A
NO
GND
1
Only for add zone
See note 1
X2M
31
L
30
N
35
Thermostat main A
35a
3
4
Only for
EHYHBH*
EHYKOMB*A*
1
Only for add zone
X2M
3
L
4
N
1
Thermostat main A
1a
33
N
32
L (Cooling K4R)
Only for
ETSH/X*
EBSH/X*D*
1
Only for add zone
X12M
21
L
22
N
15
Thermostat main A
19
10
N
9
L (Cooling K4R)
Only for
EB/DLQ*C*V3
1
Only for
Control box
X8M
7 N
X2M
1
N
X1M
L
INDOOR
6 L
N
L (Cooling K4R)
Radiator only
4D143269
MULTI IO BOX
(TFV only)
A2P
1.1
3.1
1.2
2.1
2.2
3.2
4.1
4.2
5.1
5.2
INDOOR
PE
N
L
N
X2M
31
L
30
N
35
Thermostat main A
See note 1
1
1
1
1
X2M
3
L
4
N
1
Thermostat main A
X12M
21
L
22
N
15
Thermostat main A
Only for
EHYHBH*
EHYKOMB*A*
Only for
ETSH/X*
EBSH/X*D*
X2M
1
N
X1M
L
INDOOR
Only for
EB/DLQ*C*V3
Only for
Control box
Special application: Single zone reversible with dehumidifier
Notes to go through before starting the unit
English Translation
X2M, X12M Field wiring terminal for AC
Earth wiring
1
Several wiring possibilities
Not mounted in switch box
Wiring depending on model
PCB
NOTES:
1 Configure as season input with no invert logic.
2 Configure as treatment input with no invert logic.
LEGEND:
A1P Printed circuit board (floor cooling connection kit)
A2P Printed circuit board (DHC Multi IO Box )
IC Terminal strip (dehumidifier)
J* Connector
M1P Pump
