3 About the kit
Installation manual
7
EKMBPP1+EKMBPP1A
Modbus adapter
4P720139-1C – 2024.11
3 About the kit
The EKMBPP1(A) kit is a Modbus interface to monitor and control the
VRV and Sky Air ranges of air conditioners, as well as the VAM and
VKM ventilation units. The interface is compatible with units that have a
P1P2 remote controller connection, allowing control of up to 16 units in
a single group. Functionality includes:
▪ Group control of unit settings (setpoint, fan speed, operation mode,
airflow direction, on/off state)
▪ Control over the lock state of individual remote controller buttons
▪ Control limiting (limit possible user adjustments to specified ranges)
▪ Control over settings specific to VAM and VKM units (fan speed,
damper control, on/off state)
▪ Unit monitoring (group and individual readback of unit data)
▪ Smart Grid control on Sky Air ranges.
3.1 Components
GND
DB-
DA+
X2M
X7M
P2
NC
P1
0V
NC
a
a
a
a
LED1~4
HAP
SS2 SS3
SS1
DS1
X1A
+V
X1A Power supply connector
X2M RS-485 connector (Modbus)
X7M P1P2 connector
LED*, HAP Status LEDs (see "6 Configuration" [4 18] for more information about LED
behaviour)
DS1 DIP switch
SS* Slide switches
