2 Specific installer safety instructions
Installation and operation manual
6
EKEACBVE + EKEXVA50~500
Option kit for combination of Daikin outdoor units with field-
supplied air handling units
4P724517-1 – 2023.06
Documentation set
This document is part of a documentation set. The complete set
consists of:
▪ Installation and operation manual:
▪ Installation and operation instructions for the control box
▪ Installation instructions for the expansion valve kit
▪ Format: paper (in the box of the control box)
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your dealer.
The original instructions are written in English. All other languages
are translations of the original instructions.
Technical engineering data
▪ A subset of the latest technical data is available on the regional
Daikin website (publicly accessible).
▪ The full set of latest technical data is available on the Daikin
Business Portal (authentication required).
1.1 Meaning of warnings and symbols
DANGER
Indicates a situation that results in death or serious injury.
DANGER: RISK OF ELECTROCUTION
Indicates a situation that could result in electrocution.
DANGER: RISK OF BURNING/SCALDING
Indicates a situation that could result in burning/scalding
because of extreme hot or cold temperatures.
DANGER: RISK OF EXPLOSION
Indicates a situation that could result in explosion.
WARNING
Indicates a situation that could result in death or serious
injury.
WARNING: FLAMMABLE MATERIAL
WARNING: MILDLY FLAMMABLE MATERIAL
The refrigerant inside this unit is mildly flammable.
CAUTION
Indicates a situation that could result in minor or moderate
injury.
NOTICE
Indicates a situation that could result in equipment or
property damage.
INFORMATION
Indicates useful tips or additional information.
Symbols used on the unit:
Symbol Explanation
Before installation, read the installation and
operation manual, and the wiring instruction sheet.
Before performing maintenance and service tasks,
read the service manual.
2 Specific installer safety
instructions
Always observe the following safety instructions and regulations.
General
WARNING
Make sure installation, servicing, maintenance and repair
comply with instructions from Daikin and with applicable
legislation (for example national gas regulation) and are
executed ONLY by authorised persons.
Unit installation (see "13Unit installation"[419])
WARNING
The fixing method MUST be in accordance with the
instructions from this manual. See "13 Unit
installation"[419].
Refrigerant piping installation (see "14Piping
installation"[422])
WARNING
The field piping method MUST be in accordance with the
instructions from this manual. See "14 Piping
installation"[422].
WARNING
Only systems using R32 or R410A refrigerant can be used
with the control box (EKEA) and the expansion valve kit
(EKEXVA).
CAUTION
Install the refrigerant piping or components in a position
where they are unlikely to be exposed to any substance
which may corrode components containing refrigerant,
unless the components are constructed of materials that
are inherently resistant to corrosion or are suitably
protected against corrosion.
Electrical installation (see "15Electrical installation"[423])
WARNING
The electrical wiring connection method MUST be in
accordance with the instructions from this manual. See
"15Electrical installation"[423].
DANGER: RISK OF ELECTROCUTION
WARNING
▪ All wiring MUST be performed by an authorised
electrician and MUST comply with the applicable
national wiring regulation.
▪ Make electrical connections to the fixed wiring.
▪ All components procured on-site and all electrical
construction MUST comply with the applicable
legislation.
WARNING
ALWAYS use multicore cable for power supply cables.
WARNING
Use an all-pole disconnection type breaker with at least
3 mm between the contact point gaps that provides full
disconnection under overvoltage category III.
