Daikin Europe NV
28
5.9.4 Free in the market available flue gas materials (C63).
The properties of the combustion determine the choices for the flue material.
The standards EN 1443 and EN 1856-1 provide the necessary information for choosing the
flow material by means of a sticker including an identification string.
The Identification string contains the following information:
A CE marking
B The standard to comply to: Metal, EN 1856-2
Plastic, EN 14471
The ID string needs to contain the following information:
C Temperature class : T120
D Pressure class : Pressure (P) or High Pressure (Hi)
E Resistance class : W (Wet)
F Resistance class in case of fire : E
Dimensions C63 Flue system (external dimensions in mm)
Parallel Concentric 80/125 Concentric 60/100
Flue pipe Air inlet Flue pipe Air inlet
ø 80
+0,3
-
0,7
ø 80
+0,3
-
0,7
ø 125
+ 2
-
0
ø 60
+0,3
-
0,7
ø 100
+
2
-
0
Flue materials of different markings must not be combined !
