34
Technician – Settings
Relaistest (Relay test)
ڀ The relay test allows connected actuators (pumps, switch-over
valves) to be actuated individually to check their function.
4 To start the test, enter the code number (factory setting 0000).
ڀ
The display shows "wrong code" if the code number is not entered
correctly. Repeat step 4 with the right code number.
5 Press the OK button.
Select OK Press
Relaistest
A1
A2
OFF
OFF
4 Select the relay (A1, A2 or A3) with the rotary knob.
5 Press the OK button to switch the relay on or off.
8 Press the Back button (Esc) to end the test.
ڀ Turn the selector switch back to
Automatic mode.
Reset
ڀ The personal settings (parameters 01 to 11) are retained, all the
other parameters are reset to the factory setting.
4 Note the personal settings in this manual.
5 To start the test, enter the code number (factory setting 0000).
ڀ
The display shows "wrong code" if the code number is not entered
correctly. Repeat step 5 with the right code number.
ڀ
If the code number is not known and to reset the code
number, hold the OK button pressed and connect the
power supply to the controller.
6 Press the OK button.
are you sure?
Select OK Press
Reset
Yes No
7 Select "Yes" using the rotary knob.
ڀ
If the settings are not to be changed, press the Back button (Esc)
or select "No" with the rotary knob and press the OK button.
ڀ The factory settings are loaded.
ڀ
For commissioning, modify the settings if necessary and turn the
selector switch back to Automatic mode.
