User’s Manual EM11A015H
intelligent Touch Manager
166
Example:
Time sequence Air conditioner 1 Air conditioner 2 Air conditioner 3
1 Valid Valid Invalid
2 Valid Valid “Unxed”
• Target (input management point)
The interlock control may not be executed when the value is out of range within the required
duration.
• Condition cleared immediately after program setup
If the input changes while the program is being edited or when toggling from disabled to enabled,
a condition may be considered cleared depending on the timing. Do not change settings when
input is about to change.
• Simultaneous status change effects
In the event where input conditions becomes true for output 1 and output 2 simultaneously and
the target of both outputs is the same with opposite On and Off the function may temporarily
show unexpected behavior.
Example:
When the program is set as follows.
Input: 1-00, 1-01 Output 1: One input status change → 1-02 turns ON
Output 2: All inputs status change → 1-02 turns OFF
Required duration: 0 min
Output 1 and Output 2 conditions are
true simultaneously.
1-00 Operating
On
Stopped
Off
1-01 Operating
On
Stopped
Off
1-02 Operating
On
Stopped
Off
When 1-02 ON or 1-02 OFF is detected on controller
(Output 1: One condition is true), 1-02 may transiently
output ON signal.
