User’s Manual EM11A015H
intelligent Touch Manager
167
Settings for the interlocking control is designed for general purposes, therefore a complex
program can be set, too.
However, the system will not issue any warning or error message even if an inconsistent or
inadequate setting is specied.
Check carefully before using.
NOTE
Once the trigger condition is true to turn On/Off output, the iTM will not execute On/Off even if
the condition remains true. A change in the status of input must be recognized.
Example:
When the program is set as follows.
Input: 1-00, 1-01, 1-02 Output 1: One input is On → 1-03 turns ON
Required duration: 0 min
1-00 Operating
On
Stopped
Off
1-01 Operating
On
Stopped
Off
1-02 Operating
On
Stopped
Off
1-03 Operating
On
Stopped
Off
Interlocking control is executed because
Output 1 condition is true when 1-00 is
operating.
Interlocking control is not executed
because Output 1 remains true although
1-00 and 1-01 are operating.
Interlocking control is not executed because
Output 1 remains true although 1-00, 1-01,
and 1-02 are operating.
Turned Off with remote controller
