2 | About the adapter
Installer reference guide
5
BRP069A61+BRP069A62
Daikin Altherma LAN adapter
4P464229-1E – 2023.11
2 About the adapter
The LAN adapter allows for app control of the heat pump system and, depending
on the model, allows for the integration of the heat pump system in a Smart Grid
application.
The LAN adapter is available in 2 versions:
Model Functionality
BRP069A61 App control + Smart Grid application
BRP069A62 App control only
Components: casing
a a
bd b b
a
c
c
e
a Wall mounting holes
b Knockout holes (wiring from the bottom)
c Knockout holes (wiring from the rear)
d Ethernet port
e Status LEDs
Components: PCB
X1A
X2A
X3A
X4A
b
a
LD1
LD2
LD3
LD4
X1A~X4A Connectors
a DIP switch
b Status LEDs
Status LEDs
LED Description Behaviour
LD1 Indication of power to the
adapter, and of normal
operation.
▪ LED flashing: normal
operation.
▪ LED NOT flashing: no
operation.
